INSTALLATION
NOTE: Allow the exhaust system to cool before assembly. This reduces the risk of personal injury
and/or material damage during installation.
TOOLS REQUIRED FOR INSTALLATION
WIRING DIAGRAM
NOTE: The wiring diagram below is only intended for reference.
Speaker
Connection box
Sensor
Red to reversing lamp +12 V
Black to earth (GND)
• Drill
• Pliers
• File
• Tape measure
• Drills
• Masking tape
• Small slotted screwdriver
• Phillips screwdriver
• Multimeter
• Black electrical tape
• Cable router
• Marker pen
