Figure 66Figure 64
Figure 63
Figure 65
22 HANDICARE 2000 SIMPLICITY / STYLE INSTALLATION MANUAL
Electrical connections 2000 Simplicity seat (manual)
2 Connect the earthing terminal (black)
to the pack and secure with the nut
(Figures 63 and 64).
3 Connect the main seat loom (brown and pink)
to the chassis loom (red and pink) – two black
connectors. (Figure 65).
4 Test the function of the powered features,
including the toggle (see pages 39-41).
5 Replace and refit the pack front cover
(Figure 66).
