Handicare 2000 SIMPLICITY - Fitting the Style Seat (Manual)

ENGLISH
Figure 69
Figure 70Figure 67
Figure 68
HANDICARE 2000 SIMPLICITY / STYLE INSTALLATION MANUAL 23
Fitting the Style seat (manual)
Fitting the Style seat
(manual)
Items required: Tools required:
• Seat • 13mm Socket
• 4mm Allen key
• No. 2 Pozi-drive
1 Remove the seat stem from the packaging
(Figure 67).
2 Attach the seat stem to the chassis
(Figure 68).
3 When lowering the seat onto the stem, ensure
the seat is in the ride position and the seat
switch roller does not get damaged by the
switch cam (Figure 69). There is a gap in the
cam where the roller will fit (Figure 70).
