GB
77
Drawer
Take out the components.
Installing accessories · Drawer
Remove the front plastic screws in the drawer
rails and discard them. Insert the screws in the
hole of the rail as illustrated. The second screw
is inserted in the rear section. Hold the rail as
far out as possible and angle the front section
downwards whilst you tighten the screws.
When installing the
drawer, the lower
knockout in the back
panel must always be
removed for the supply of
convection air.
1
