H&S 175 - SPECIFICATIONS

H&S MODEL 175
MANURE SPREADER
Your new H&S spreader has been manufactured of the finest quality materials and compo-
nents. The performance you get from your machine is largely dependent upon how well you
read and understand this manual and apply this knowledge. There is a right and a wrong way
to do everything. Please do not assume that you know how to operate and maintain your
spreader before reading this manual carefully. Keep this manual available for ready reference.
SPECIFICATIONS
MODEL NO.
Top Flare Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63-1/2’’
Inside Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54’’
Inside Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11’-1’’
Inside Depth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25-3/4’’
Overall Width W/9:00 x 20 Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86-1/2’’
Overall Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17’-8’’
Overall Loading Height (Top of Flare) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47-1/2’’
Overall Height W/Hyd. Endgate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51’’
Diameter of Beater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27’’
Weight W/9:00 x 20 Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2030 Lbs.
Capacity (Old Rating) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175 Bu.
Capacity - Cu. Ft. Struck Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Rear Hydraulic Endgate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Optional
Semi Liquid Rear Pan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Optional
Upper Beater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Optional
Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Two Speed Gearbox
Variable Speed Hydraulic Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Not Available
Front Splash Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Standard
PTO Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 540 RPM
NOTE
Determine right or left side of spreader by viewing it from the rear. If instructions or parts
lists call for hardened bolts, they are identified with three lines or marks on the head.
