H&S 2117 - User Manual

H&S 2117
32 pages
Save Page as PDF
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
Loading...
Manufactured By
H&S MANUFACTURING CO.,INC.
P.O. BOX 768 (715) 387-3414 FAX (715) 384-5463
MARSHFIELD, WISCONSIN 54449
WARNING
Revision #01
Starting Serial #911PD17001
HSMFG1018
Part #75658
READ AND UNDERSTAND THIS MANUAL
BEFORE OPERATING THIS EQUIPMENT.
UNSAFE OPERATION OR MAINTENANCE OF
THIS EQUIPMENT CAN RESULT IN SERIOUS
INJURY OR DEATH.
21172117
21172117
2117
OPERAOPERA
OPERAOPERA
OPERA
TT
TT
T
OR’S MANUOR’S MANU
OR’S MANUOR’S MANU
OR’S MANU
ALAL
ALAL
AL
Standard Duty
Spreader

Table of Contents

Questions and Answers

  • A
    Aimee CruzAug 6, 2025
    Why is the beater not turning on my H&S 2117 Spreader?
    • D
      Danielle PerezAug 7, 2025
      If the beater on your H&S Spreader isn't turning, several factors could be at play. Ensure the tractor PTO is engaged and the beater itself is engaged. Check the main drive shear bolt; if it's sheared, replace it. Inspect the front drive chain for any issues—if it's off, broken, or missing, repair or replace it. Also, verify the control cable adjustment. Finally, examine the splined beater insert for wear or sheared splines; replacement of both the insert and the gearbox output shaft may be necessary.
  • J
    james93Aug 16, 2025
    What to do if the apron does not turn on H&S 2117 Spreader?
    • D
      Dawn RobertsAug 16, 2025
      If the apron on your H&S Spreader isn't turning, there are several possible causes. First, make sure the tractor PTO is engaged. If it is, check the main drive shear bolt; if sheared, it will need to be replaced. Also, inspect the apron drive shear bolts and replace them if they are sheared. Examine the front drive chain and the apron worm drive chain, replacing or repairing them if they are off, broken, or missing.
  • C
    Chelsea AvilaAug 27, 2025
    How to fix a H&S 2117 beater that will not disengage?
    • H
      henrygregoryAug 27, 2025
      If the beater on your H&S Spreader won't disengage, it could be due to a control cable out of adjustment; in this case, you should adjust the control cable. Another potential cause is binding in the control linkage; check the control linkage and ensure it moves freely.

Summary

Warranty Policy

Warranty Registration

Form for registering the product warranty with the manufacturer.

Manufacturers Statement

Dealer Pre-Delivery Checklist

Dealer Delivery Checklist

Safety Introduction

Safety Signal Words and Transport Speed

Specific Warning Decals

Additional Safety Warnings

General Operating Safety

Cap Screw Torque Specifications

Setup and Assembly

Preparing Manure Spreader

Steps for preparing the spreader before initial use.

Transporting Guidelines

Preparing for Operation

Tractor Hitch and PTO Connections

Instructions for connecting the spreader hitch and PTO to the tractor.

Operation Procedures

Loading and Spreading

Guidance on loading material and operating the spreader for spreading.

Adjustments Section

Drive Chain Adjustment

Procedure for adjusting the tension of the drive chain.

Speed Control Adjustment

Adjusting the apron speed and beater control mechanism.

Further Adjustments

Apron and Drive Chain Adjustment

Adjusting the apron and its drive chain tension.

Wheel Hub Adjustment

Procedure for adjusting the wheel hubs and bearings.

Service and Repairs

Shear Bolt Replacement

Information on shear bolts for main and apron drives and their replacement.

Component Service

Beater Maintenance

Inspection and maintenance of the beater for wear or damage.

Tire and Wheel Checks

Procedure for checking tire pressure and wheel torque.

Optional Equipment

Optional Features Overview

Description of optional features like rear pan, hydraulic endgate, and top beater.

Lubrication Guide

Grease Fittings and Gearbox

Information on grease fittings, gearbox oil, and drive chains lubrication.

PTO Assembly Lubrication

Specific lubrication and precautions for the PTO assembly.

Grease Zerk Locations

Decal Location and List

Decal Visual Guide Part 1

Decal Visual Guide Part 2

Decal Visual Guide Part 3

Trouble Shooting Guide

Service Notes

Technical Specifications

H&S 2117 Specifications

General IconGeneral
BrandH&S
Model2117
CategorySpreader
LanguageEnglish
