ITEM PART NO. DESCRIPTION
1. 4C9 Lock Collar
2. 4C7 Flange
3. 4C8 Bearing
4. 4C4 Input Sprocket 13T
5. 5B10 Key 1/4’’ x 1’’
6. 80N7 Input Shaft
7. 3G21 Snap Ring
9. 80N9 Front Frame
10. 80N10 Front Poly Shields
11. 80N11 Front Post Spacer
12. 80N12 Front Post
13. 80N13 Center Bearing Bracket
14. 17G45 Implement Yoke Shield
15. 80N14 Pole Assembly
16. 12N14 Jack Mount
17. 12N11 Jack
18. 12N12 Jack Handle
19. 12N13 Jack Pin & Chain
20. F56 Linchpin
21. 80N15 Shaft Guard
22. 80N16 #50 Roller Chain - 118 Pitches
23. X141 40T Sprocket
24. 5B10 Key 1/4’’ x 1’’
25. 80N18 Side Shaft
26. 80N19 Bearing Cover
27. 80N20 Bearing Holder
28. 80N21 Bearing
29. 80N22 Bearing Assembly
30. 80N23 Shifter Angle
31. BFR220 Cable Clamp
32. ES4 Thimble
33. 80N24 Chain Tightener
34. ST28 24T Sprocket
ITEM PART NO. DESCRIPTION
35. 80N25 #50 Roller Chain - 50 Pitches
36. 80N26 17T Sprocket
37. 80N27 Gearbox Mounting Spacer
38. 80N28 Coupler
39. 16SV91 Spindle Bolt
40. 12N16 Spindle
41. 12N17 Seal
42. 12N18 Inner Bearing
43. 12N19 Inner Race
44. 12N20 Hub
45. 12N21 Outer Race
46. 12N25 Outer Bearing
47. B4 Washer
48. B3 Nut
49. 12N23 Dust Cap
50. 12N22 Hub Bolt
51. RG127 Wheel 15 x 6
52. 80N29 Back Cross Beam
54. 80N31 Beater Shut-Off Bracket
55. 5B6 Spring
56. 12N51 Bolt 3/8’’ x 2-3/4’’ GR.5
57. X67 Washer 3/8’’
58. 12N48 Shifter Bracket
59. K93 Lock Nut 3/8’’
60. ES5 Cable Clamp
61. 80N33 Cable
62. 3G22 Roll Pin 5/16’’ x 1-3/4’’
63. R10 Bolt 1/2’’ x 1-1/4’’ GR.5
64. B31 Cotter Pin
65. 80N74 Shear Hub
66. 16SV289 Shear Bolt 5/16’’ x 1-1/2’’ GR.2
67. D81 Lock Nut 5/16’’
68. 23N75 Snap Ring
-25-
FIGURE 1
MODEL 80
COMPONENT PARTS
