ITEM PART NO. DESCRIPTION
1. F54 PTO Rubber Shield
2. 12N1 Shield
3. F56 Clip Pin
4. F92 Front Shield Bracket
5. 12N85 Front Poly Shield
6. 12N86 Front Side Shield
7. 12N4 Front Housing
8. 12N5 Cover
9. 12N6 Rear Housing
10. F69 Shield Bracket
11. 12N87 Side Shield
12. 12N8 Side Shield Bracket
13. R10 1/2’’ x 1-1/4’’ Bolt, GR.5
14. 12N10 Pole Assembly
15. 12N11 Jack Assembly
Not Shown 12N9 Jack Gear Replacement Kit
16. 12N12 Jack Handle
17. 12N13 Jack Pin and Chain
18. 12N14 Jack Mount
19. 12N15 Axle Tubing
20. B10 Spindle Bolt GR.5
21. 12N16 Spindle
22. 12N17 Seal
23. 12N18 Inner Bearing
24. 12N19 Inner Race
25. 12N20 Hub
26. 12N21 Outer Race
27. 12N22 Hub Bolt
28. B4 Washer
29. B31 Cotter Pin
30. B3 Nut
31. 12N23 Hub Cap
32. 12N24 Wheel
33. 12N25 Outer Bearing
34. 12N88 LH Side Panel
35. 12N89 Front Bolt In Panel
36. 12N90 RH Side Panel
37. 12N96 Front Side Shield Bracket
38. WM135 Angle
Not Shown 12N79 Complete Hub Assembly
-27-
FIGURE 2
MODEL 125
SHIELDS, AXLE AND POLE ASSEMBLY
