ITEM PART NO. DESCRIPTION
1. 12N26 Tightener Rod
2. F73 Snap Ring
3. F13 20T Sprocket
4. 12N30 Spacer (2)
5. R10 1/2’’ x 1-1/4’’ Bolt GR.5
6. 9S17 1/2’’ Lock Nut
7. 12N27 Front Adjustment Plate
8. F16 Lock Collar
9. F14 Bearing Flange
10. F115 Bearing (Grease Type)
11. 5B9 3/8’’ x 1-1/4’’ Woodruff Key
12. 12N28 Front Shaft
13. 5B10 1/4’’ x 1’’ Woodruff Key
14. 12N29 Pillow Block Bearing
15. 12N30 Spacer
16. F26 5/16’’ x 2-1/4’’ Roll Pin
17. 12N91 #60 Roller Chain 99 Pitches
18. 23N191 Shear Sprocket 30T
19. 12N92 Side Shaft
20. 12N33 Bearing
21. 12N34 Bearing Cover
22. 12N35 Bearing Holder
23. 12N36 Bearing Assembly
24. D12 Connector
25. R16 Shaft Support
26. F95 Bearing Flange Guard
27. 12N37 SMV Sign Holder
28. F97 SMV Holder
29. 12N38 LH Beater Stub Shaft
30. 12N39 Beater Blade
31. 12N40 Beater
32. R34 RH Beater Stub Shaft
33. 12N41 #60 Chain 64 Pitches
34. D26 30T Sprocket
35. A19 1/2’’ x 3-1/2’’ Carr. Bolt GR.5
36. 12N42 Idler Sprocket
37. 12N43 Spacer
38. 12N44 Washer
39. D100 Ring for Beater Brace
40. 12N45 Gearbox Brace
41. 12N46 Beater Rear Support
42. D18 16T Sprocket
43. G35 Stake Nut
44. D23 16T Sprocket
45. F31 Cable Loop
46. 12N47 Cable
47. A14 3/8’’ Nylock Nut
48. 12N48 Shut-Off Lever
49. 12N49 Shut-Off Bracket
50. 5B6 Shut-Off Spring
51. 12N51 3/8’’ x 2-3/4’’ Bolt GR.5
52. 23N190 Shear Hub
53. 23N189 Snap Ring
54. D31 5/16’’ x 1-1/2’’ Shear Bolt GR.5
55. D81 5/16’’ Lock Nut
56. 12N82 Front Shaft Shield
57. 12N84 Back Side Shaft Shield
58. 12N83 Front Side Shaft Shield
Not Shown D38 #60 Offset Link
Not Shown D39 #60 Connector Link
-31-
FIGURE 4
MODEL 125
FRONT SHAFT, SIDE SHAFT AND BEATER
