-35-
ITEM PART NO. DESCRIPTION
1. 12N52 Rubber Flap Angle
2. 12N53 Rubber Flap
3. R70 Cotter Pin
4. R3 Pan Spacer
5. 12N54 Pan
6. 12N55 RH Pan Support
7. 12N56 LH Pan Support
8. 12N57 Trip Lever Plate
9. R30 1/2’’ x 2’’ Bolt
10. R26 Spring Angle
11. R27 Spring
12. R60 Trip Lever Stop
13. 12N58 Trip Lever
14. R31 Clip
15. 12N59 Trip Rope
16. 12N60 40T Sprocket
17. 12N41 #60 Chain 64 Pitches
18. D20 Chain Tightener
19. 12N103 Brace Gearbox to Drive Shaft
20. A39 Spacer
21. A4 Conveyor Drive Sprocket 6T
22. 5B9 3/8’’ x 1-1/4’’ Key
23. 12N62 Drive Shaft
24. 12N63 67XH Slat with Att. Link
25. 11S26 67XH Att. Link LH
26. 11S27 67XH Att. Link RH
27. 11S29 67XH Connector Links
28. 12N64 67XH Complete Apron
29. 12N65 6T Idler Sprocket
30. 12N66 Spacer
31. A7 1/2’’ x 9-1/2’’ Bolt GR.5
32. 12N67 Idler Shaft
33. 12N97 Angle for Rubber
34. 12N69 Front Rubber
35. 12N93 Floor Poly Bonded
36. 12N50 Brace
37. 12N94 Front Floor Brace
38. 12N95 Rear Floor Brace
Not Shown D38 #60 Offset Link
Not Shown D39 #60 Connector Link
Not Shown D92 Apron Slow Down Sprocket 48T
Not Shown 12N80 Apron Speed Up Sprocket 32T
39. 12N104 Short Drive Shaft Brace
40. 12N105 Wedge
FIGURE 6
MODEL 125
APRON, CHAIN, FLOOR & PAN
