ITEM PART NO. DESCRIPTION
1. G1 Seal
2. G2 Bushing
3. 12N98 36T Gear
4. G4 Capscrews (8)
5. G5 Drain Plug
6. G6 Gear Housing - Lower
7. G7 Expansion Plug
8. G2 Bushing
9. G9 Snap Ring
10. 12N99 Low Speed Output Shaft
11. G11 1/4’’ x 1-1/8’’ Key
12. G12 5/16’’ x 1’’ Key
13. G13 Gasket
14. G14 Gear Housing - Top
15. 12N100 Shaft
16. G16 Bushing
17. G17 24T Gear
18. G18 Bearing
19. G55 Snap Ring
20. G20 Cap
21. G9 Snap Ring
23. G22 1/4’’ x 7/8’’ Key
24. G23A 5/16’’ x 1-1/4’’ Square Key
25. G24 Plug Vent
26. G25 Snap Ring
27. G26 3/8’’ x 1-1/4’’ Key (Hardened)
28. 5B9 3/8’’ x 1-1/4’’ Key
29. G28 Hi-Speed Output Shaft
30. G29 16T Gear
31. G53 Bearing
32. G69 Shim (When Needed)
33. G55 Snap Ring (2)
34. G33 Bearing
35. G34 Seal
36. G35 Stake Nut
37. G95 1/8’’ x 1-1/2’’ Cotter Key
38. G37 Yoke
39. G38 Spring
40. G39 Clutch Rod
41. G40 Seal
42. G41 Seal
43. 3G19 Snap Ring
44. L3G24 Bearing
45. G44 Spacer Ring
46. 12N101 Worm
47. G46 Clutch 18T Spline
48. D7A Gearbox Complete
49. G92 Shim (When Needed)
50. G87 Plug 1/8-27 NPT
51. G54 Race
52. 3G18 Race
-39-
FIGURE 9
MODEL 80 & 125
GEAR BOX
