H&S 80 - Model 125 Specifications

H&S MODEL 125
MANURE SPREADER
Your new H&S spreader has been manufactured of the finest quality materials and
components. The performance you get from your machine is largely dependent upon
how well you read and understand this manual and apply this knowledge. There is a
right and a wrong way to do everything. Please do not assume that you know how to
operate and maintain your spreader before reading this manual carefully. Keep this
manual available for ready reference.
SPECIFICATIONS
Top Flare Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54’’
Inside Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48’’
Inside Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10’-6’’
Inside Depth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22’’
Overall Width W/10:00 x 15 Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80’’
Overall Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15’-3’’
Overall Length with Rear Pan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15’-6’’
Overall Height W/10:00 x 15 Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43’’
Wheel Tread . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68’’
Diameter of Beater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22’’
Drive Worm - Timken . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Single Speed
Weight W/10:00 x 15 Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1430 Lbs.
PTO Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 540 RPM
Capacity - Cu. Ft. Struck . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Old Rating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125 Bu.
Rear Pan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Optional Equipment
Swing Away Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Standard Equipment
NOTE
Determine right or left side of spreader by viewing it from the rear. If instructions or
parts lists call for hardened bolts, they are identified with three lines or marks on the
head.
H&S MANUFACTURING CO. INC.
2608 S. Hume Ave.
P.O. Box 768 – Telephone (715) 387-3414
FAX (715) 384-5463
MARSHFIELD, WI 54449
H&S WAREHOUSE Rt. #5 and 76
P.O. Box 1260 – Telephone (716) 736-7595
FAX (716) 736-7596
RIPLEY, NY 14775
