5
A. INTRODUCTION
A.1 About the manual
The H&S firm (“Manufacturer”) designed and
created the device in accordance with the
associated safety standards to ensure the safety of
personnel and the entire operating system.
Each rake is supplied with a copy of this manual
which the operator must read in full before using
the equipment. The manual contains all information
relating to transportation, use and maintenance of
the equipment, as well as safety instructions.
Poor knowledge of the operating system can lead
to accidents and therefore damage to the
equipment. Although the Manufacturer provides the
Customer with all information relating to the rake
operation, use and maintenance, the Customer is
still expected to read this manual and take note of
all the instructions herein.
The manual provides all the necessary instructions
on how to ensure optimal working order and safety.
The manual was drawn up according to the current
technical and structural characteristics of three
models of rake and does not cover previous similar
models. The Manufacturer therefore reserves the
right to modify models in production in the interest
of improvement or due to any new legislation
(Machinery Directive), without being obliged to
modify previous models.
This manual is integral to the rake and must
therefore be kept intact, clean and in good
condition. It should also be in a container, either on
the frame of the rake or in the tractor cabin, where it
can be easily accessed for consultation.
The manual must be kept in its container if the rake
is taken out of service. Ask the Manufacturer for a
duplicate copy if the original manual is lost.
Please contact the H&S Dealer for any clarifications
relating to the instructions in this manual.
Symbols used in this manual:
HAZARD
Indicates an imminently hazardous situation
that, if not avoided, will result in death or
serious injury.
WARNING
Indicates a potentially hazardous situation that, if
not avoided, could result in death or
serious
injury. It is also used to alert against unsafe
practices.
CAUTION
Indicates a potentially hazardous situation that,
if not avoided, may result in minor or
moderate
injury. It is also used as a reminder of good
safety practices.
IMPORTANT
The operator must take the respective information
into account.
Note indicates that the information referred to can
facilitate the operator work.
A.2 Identification
An identification plate is applied to each machine:
You must have this information at hand when
requesting assistance and spare parts.
IMPORTANT
It is strictly forbidden to alter and/or eliminate the
data on the serial plate. The operator must check
the legibility of the data on a regular basis and
inform the Manufacturer if it becomes in any way
illegible. The Manufacturer will then replace the old
plate with a new one bearing the same data.
A.3 Main components and technical data
1. Three-point hitch
2. Cardan shaft attachment
3. Steering damper spring
4. Lateral protection screens
5. Working rotate unit
6. Tine-holder arm
7. Lateral deflector
8. Wheels
9. Windrowing tines
10. Arm-holder supports
11. Frame
12. Bearing foot
13. Adjusting lever of tine height
14. Tow hitch
Type: XXXXXXXX Model
Serial N. XXXXXXX-XX
MFG: 2015 DEL: 2015
