2 Truck Introduction
2.1 General
A series mini range electric stacker described in this manual should work under low working
strength and its continuous working time should not surpass one hour.
Users can get relevant information as rated load from the product model. Model CTD10-AMC1-SZ
as an example:
CTD10-AMC1-SZ Mode
CDD Electric stacker
CTD Straddle legs type
10 Rated load capacity×100kg
A Product serial number
M Mini Range
C1、C2 Controller type
SZ
Double column Mast (without “SZ” is single column Mast)
Truck body system
– Beautiful and compact outline, concise and fluent line.
– Chassis welded by high-performance steel plate guarantees enough load capacity.
– Chassis adopts 4-wheel structure, including one drive wheel, one auxiliary wheel as
stabilizing and four load wheels, thus guarantee the good stability and safe travelling.
Driving system
