FUNCTIONAL DESCRIPTION HI 9214FUNCTIONAL DESCRIPTION HI 9214
FUNCTIONAL DESCRIPTION HI 9214FUNCTIONAL DESCRIPTION HI 9214
FUNCTIONAL DESCRIPTION HI 9214
1) °C button, located on the top of the meter, to display
temperature measurements.
2) CFM to confirm calibration values.
3) CAL to enter calibration mode or to select buffer.
4) ON/OFF to switch the instrument on or off.
5) LCD display.
6) Screw-type socket for combination pH electrode with built-in
temperature sensor.
ins
e
rum
n
s
ON
OFF
CAL
CFM
p
H
HI 9214 stick pHmeter
1
2
3
4
5
6
HI 8915
Range pH 0.00 to 14.00
mV 0 to ±1999
°C 0.0 to 100.0
Resolution pH 0.01
mV 1
°C 0.1
Accuracy pH ±0.01
(@20°C/68°F) mV ±1
°C ±0.5
Typical EMC pH ±0.02
Deviation mV ±1
°C ±0.8
pH Calibration Manual 2 point through
offset and slope trimmers
Offset Calibration ±1 pH
Slope Calibration from 85 to 105%
Temperature Automatic from 0 to 70°C (32 to 158°F)
Compensation or fixed at 25°C (77°F)
with temperature probe detached
Electrode HI 1230B combination, double-junction,
gel-filled pH electrode BNC
and 1 m (3.3') cable (included)
Temperature HI 7669AW (included)Probe
Input Impedance 10
12
ohm
Recorder Output 100 mV/pH
1mV/mV
10mV/°C
Battery Type 1 x 9 volt
Life 100 hours of continuous use
Environment 0 to 50°C (32 to 122°F);
max 95% RH non-condensing
Dimensions 185 x 82 x 45 mm
(7.3 x 3.2 x 1.8")
Weight 570 g (1.3 lb.)
SPECIFICATIONS HI 8915SPECIFICATIONS HI 8915
SPECIFICATIONS HI 8915SPECIFICATIONS HI 8915
SPECIFICATIONS HI 8915
