FUNCTIONAL DESCRIPTION HI 8915FUNCTIONAL DESCRIPTION HI 8915
FUNCTIONAL DESCRIPTION HI 8915FUNCTIONAL DESCRIPTION HI 8915
FUNCTIONAL DESCRIPTION HI 8915
1) BNC socket for combination pH or ORP electrodes.
2) LCD display.
3) HOLD to freeze the reading on the display.
4) mV to display the mV (ORP) readings when using an ORP
electrode or the mV equivalent to the pH values when using
a pH electrode.
5) OFFSET trimmer for OFFSET calibration of pH
6) + recorder output (mV output, positive connection).
7) Phono plug socket for temperature probe HI 7669AW.
8) ON/OFF to switch the instrument on or off.
9) pH to display the pH value.
10) °C to display the temperature measurement (when the
temperature probe is disconnected, the LCD will show 25°C).
11) SLOPE trimmer for SLOPE calibration of pH.
12) - recorder output (mV output, negative connection).
pH
ON
OFF
HOLD
mV
°C
pH
HI 8915
ATC
pHmeter
+-
mV OUTPUT
SLOPE
4.01
10.01
OFFSET
6.86
7.00
CALIBRATION
1
7
2
9
4
10
5
11
8
3
6
12
SPECIFICATIONS HI 8314SPECIFICATIONS HI 8314
SPECIFICATIONS HI 8314SPECIFICATIONS HI 8314
SPECIFICATIONS HI 8314
HI 8314
Range pH 0.00 to 14.00
mV 0 to ±1999
°C 0.0 to 100.0
Resolution pH 0.01
mV 1
°C 0.1
Accuracy pH ±0.01
(@20°C/68°F) mV ±1
°C ±0.4
Typical EMC pH ±0.05
Deviation mV ±5
°C ±1
pH Calibration Manual 2 point through
offset and slope trimmers
Offset Calibration ±1 pH
Slope Calibration from 85 to 105%
Temperature Automatic from 0 to 70°C (32 to 158°F)
Compensation or fixed at 25°C (77°F)
with temperature probe detached
Electrode HI 1230B combination, double-junction,
gel-filled pH electrode BNC
and 1 m (3.3') cable (included)
Temperature HI 7669AW (included)Probe
Input Impedance 10
12
ohm
Battery Type 1 x 9 volt
Life 100 hours of continuous use
Environment 0 to 50°C (32 to 122°F);
max 95% RH non-condensing
Dimensions 185 x 82 x 45 mm
(7.3 x 3.2 x 1.8")
Weight 570 g (1.3 lb.)
