User’s Manual
APPENDIX
SPECIFICATIONS
Driving system TFT Color LCD
Size 19.0"
LCD Panel
Pixel pitch 0.294mm(H) x 0.294mm(V)
H-Frequency 31KHz – 80KHz
Video
V-Frequency 55 – 75Hz
Display Colors 16.7M Colors
Max. Resolution 1280 x 1024 @75Hz
Plug & Play
VESA DDC2B
TM
ON Mode ≤36W
Power Saving Mode ≤2W
EPA ENERGY STAR
®
OFF Mode ≤1W
Audio output Rated Power 1 W rms (Per channel)
Input Terminal
VGA
DVI-D (Dual-Input Model)
Maximum Screen Size
Hor. : 376.32mm
Ver. : 301.06mm
Power Source 100~240VAC,50±3Hz,60±3Hz
Environmental
Considerations
Operating Temp: 5° to 40°C
Storage Temp.: -20° to 65°C
Operating Humidity: 20% to 80%
Dimensions
406.8 (W) x 431.5(H) x 200.5(D) mm
16.0 ”(W)×17.0”(H)×7.9 ”(D)
Weight (NW) 5.2 kg(11.5 lb)
***The above specification is subject to actual product specification and is subject to change without
prior notice.
NOTES:
The Maximum Resolution will depends on the display card supporting. Related issue can refer to
www.hannsg.com FAQ section.
20
