User’s Manual
10
MAKING CONNECTIONS
CONNECTING TO A PC
Turn off your computer before performing the procedure below.
1. Plug one end of the 12V DC adapter to the LCD monitor’s DC 12V input socket, plug one end of
the AC power cord to the 12V DC adapter AC input socket, and the other end of the AC power
cord to Wall outlet.
2. Connect one end of the DP cable (optional) to the back of the monitor and connect the other end
to the computer’s DP port.
3. Connect one end of the HDMI cable to the back of the monitor and connect the other end to the
computer’s HDMI port.
4. Connect one end of the HDMI to DVI cable (optional) to the back of the monitor and connect the
other end to the computer’s DVI port
5. Connect one end of the VGA cable (optional) to the back of the monitor and connect the other
end to the computer’s VGA port.
6. Connect the audio cable between the monitor's audio input and the PC's audio output (green
port).
7. Turn on your monitor and computer.
Figure.2. Connecting to a PC
1 Power DC Input 2 DP Input
3 HDMI Input 4 VGA Input
5 AUDIO IN
