User’s Manual
MAKING CONNECTIONS
CONNECTING TO A PC
Turn off your computer before performing the procedure below.
1. Connect one end of the Type-C cable to the back of the monitor and connect the other end to the
computer’s Type-C port.
2. Connect one end of the Type-C cable to the back of the monitor and connect the other end to the
PowerAdaptort.
3. Connect one end of the HDMI cable (optional) to the back of the monitor and connect the other
end to the computer’s HDMI port.
4. Connect the audio cable between the monitor's audio input and the PC's audio output (green
port).
5. Turn on your monitor and computer.
Figure.2. Connecting to a PC
1 LINE OUT 2 HDMI Input (optional)
3 Type-C Input 4 Type-C Input
9
