Handle installation
• Open the door and carefully pull back the door gasket in the areas where the handle screws are placed.
• Align the handle with the screws and tighten using a screwdriver until the handle is flush against the
doorframe. To insure a proper fit, alternate tightening of the screws before completely tightening either
screw.
• Carefully press the door gasket into its original position.
CAUTION: Do not over-tighten the screws as this may cause damage to the handle or to the stainless steel door.
Reversing the door
A. Open the door to a 90degree angle, take out the 2 screws from the lower door axis (1) remove the door (2)
and the axis plate from the door.
B. Take out the 3 hinge screws from the top right hinge (3) and remove it.
C. Remove the decorative covers (5) from the top left of the cabinet and install the new top hinge (4) at top of
the cabinet with 3 screws.
D. Place the decorative covers over the right hinge.
E. Install the door once correctly aligned.
