DG3 Controller – Installation and Operation
Manual
540846-3 page 22 of 64 25/09/2015
Transferring the database from the USB stick to the DG3
Insert the USB stick into the port in the front of the
controller. The DG3 will automatically find, transfer and
save the database as shown.
When it has finished, a request to remove the USB stick
will appear as shown.
The DG3 will re-boot once the USB stick is removed and
will show the last inputted destination code. However,
this number may not correspond with the new list loaded,
in which case 'Bad destination' will then be shown: try
inputting a number from the new list.
If the controller is in 'remote' mode (i.e. the signs are
being driven by an on-board computer), its screen will
show 'Idle'.
Note that if the Eric.BIN file is corrupt, or no valid files
can be found on the stick, the controller will show the
following message 'Remove USB drive:' and will flash
and beep continuously until the USB stick is removed,
whereupon the DG3 will reboot. This will not make any
change to the current loaded file.
USB:
Loading…
|||||||||||||||||||||||||||||||||||
|||||||||
USB:
Please wait…
|||||||||
USB:
Found ERIC.BIN
|||||||||
USB:
Drive found
|||||||||
USB:
Load completed
Remove USB drive:
|||||||||
DERIC-G3 V1.12
abcde
|||||||||||||||||||||||||||||||||||
USB:
Load completed
|||||||||
USB:
ERIC.BIN Not Found
Remove USB drive:
To Next Page
Loading...
