DG3 Controller – Installation and Operation
Manual
540846-3 page 34 of 64 25/09/2015
Message is played twice when input active (volts on input)
Destination
Hanvox
(inverted)
As above, but input sensing is inverted (volts = inactive; no volts = active).
Note: When using the Extensions box in Helen software, several different configuration codes can be
added if required; they should be separated by a comma.
6) Displaying ‘Bus reversing’
Values BR and BRI are for 'Bus reversing'. The bus reversing message is programmed under a destination
code whose most significant two characters are 'BR' - for example: BR01 (or BR00000001) or 0000 BR01
for route browse.
The destination code should only contain a message for the signs which are to show it, i.e if the front sign
is not to change, no message content should be entered for the front sign for this destination.
Whilst the input is active (volts on input), the signs will show the programmed
message.
As above, but input sensing is inverted (no volts = active).
Note: The bus reversing message can also be set using a destination code of 9999 (please refer to
Emergency message).
System options
The system function codes determine how the DG3 is set up as a controller. To use this feature, the lock
code must be entered, 'System?' found from within the list and then selected using the F/E key. On the
controller screen, there are currently 9 options plus 'Back' (available in this edition). The active option is
bright whilst the other two are dimmed. Use the up and down arrow keys to navigate between each one.
An example screen looks like this:
The list of system options available in the DG3 controller is provided in Appendix B: System Options.
DA - Daylight Saving 1
AS - Auto Speed
57600
Back
