OperationPage EN-22
(15)
(26)
1. Open up the cap (26) of the water
tank (15).
2. Pour up to 2.5 litres of fresh tap water into
the water tank and close the cap again.
Using the water dispenser
(28)
(27)
• Push the water container against the
dispenser pad (27) of the water dispens-
er (28).
Cold water will begin to pour into the con-
tainer.
Water will stop being dispensed when you
remove the container from the dispenser
pad or when there is no more water in the
water tank (15).
Pictograms
The following pictograms can be found on the
fruit/vegetable drawer (6):
This means that you can store fresh fruit and
fresh vegetables in the fruit/vegetable draw-
er (see “Chilling food” on page EN-23).
The following pictograms can be found on the
fresh food drawer (13):
This means that you can temporarily
store fresh fruit and vegetables, as well as
chilled drinks and raw meat, raw fish, sea-
food and similar in the fresh food draw-
er (see “Chilling food” on page EN-23).
