Hansen APM User Manual

15
APM-001e
AUG 2015
PARTS LIST FOR APM (AMMONIA)
ELECTRICAL
Control Board 20-1836
Shield for above 20-2271
Ground Wire for above 20-2270
Power Board 20-1845
3A (amp) fuse (5mm x 20mm) Type F
for Power Board
20-1698
Cable, Control Board 20-1837
Pressure Transducer 20-1857
Temperature Sensor 20-2303
High Side Level Sensor 77-0796
Drainer & Low Side Level Sensor 77-0535
Solenoid Coil Kit, 230V for DIN plug 70-1093
Solenoid Coil Kit, 115V for DIN plug 70-1092
MECHANICAL
Solenoid Tube/Plunger Kit 70-1059
Water Solenoid Valve (D), Less Coil HS2B/1
APM Bubbler 20-1959
Strainer/Orifice Screen Assembly Kit
includes Strainer/Orifice Screen
Assembly and necessary O-Rings
20-2177
Water Flow Controller 20-1985
Removable Seat/Orifice Kits
For Solenoid Valve (B) or (C) 70-1068
For Solenoid Valve (A) 70-1069
80 psid Check Valve 20-2379
Foul Gas/Liquid Line Strainer Kits
include Strainer Basket and O-Ring
78-1010
PARTS LIST FOR APMF (HALOCARBON)
ELECTRICAL
Control board 20-1836
Shield for above 20-2271
Ground Wire for above 20-2270
Power board 20-1845
3 amp fuse (5mm x 20mm)
Fast-Acting for Power board
20-1698
Cable, control board 20-1837
Pressure transducer 20-1857
Temperature sensor 20-2303
High side level sensor 77-0796
Drainer and low side level sensor 77-0794
Solenoid coil kit, 230V with DIN plug 70-1093
Solenoid coil kit, 115V with DIN plug 70-1092
MECHANICAL
Solenoid tube/plunger kit 70-1059
APMF bubbler 20-2282
Strainer/orifice screen assembly kit
includes strainer/orifice screen assembly
and necessary o-rings
20-2285
Removable seat/orifice kits
For solenoid valve (C) 70-1068
For solenoid valve (A) or (B 70-1069
80 psid check valve 20-1949
Foul gas/liquid line strainer kit
Includes strainer basket and o-ring
78-1010
ORDERING INFORMATION, PURGER
Cat. No. Description
APM
Auto-Purger M, 4 points,
for ammonia systems
APMF
Auto-Purger M, 4 points,
for halocarbon systems
To Order: Specify catalog number, refrigerant and voltage.
Standard voltage is 115V 50/60Hz;230V 50/60Hz, is available.
CSA and CE mark available.
ORDERING INFORMATION, OPTIONAL VALVE
PACKAGE
Cat. No. Description
VPM Valve Package for ammonia systems
VPMF Valve Package for halocarbon systems
To Order: Specify catalog number and refrigerant. The VPM
optional isolation valve package consists of three flanged
welded assemblies which include the necessary shut-off
valves and gauge valves for the foul gas line, suction line,
and liquid line. The VPMF for halocarbons also includes
filter dryers and moisture indication sight glasses.

Hansen APM Specifications

General

Brand	Hansen
Model	APM
Category	Auto-Purgers
Language	English
