Copyright Qingdao Hantek Electronics Co., LTD HDP10000 series user manual
11
settings are then saved in M5 position. Operations for M6 ~ M10 are the same as those
for M5.
4.
Some buttons have texts on them, indicating that the button has a function that you can
press and release before pressing the button to access it. For example, if you
press and release before pressing , you will access the M5 function.
5.
Turn on or off the output.
6. Output terminal
Positive output terminal (red) : connected to the positive terminal of the load.
Negative output terminal (black) : connected to the negative load terminal.
Ground terminal (green) : connected to the machine casing and ground cable (ground
terminal of power cable), and is grounded.
7. USB quick charge port
The output voltage of USB quick charge ranges from 5V to 12V, providing a maximum
output power of 18 W. The USB quick charge automatically adjusts the output voltage
and current according to the identified quick charge protocol. Typical output voltages
and currents are 5V@3.4A, 9V@2.0A, and 12V@1.5A. When charging electronic
devices that do not have the function of quick charge, the standard 5V charge will be
provided.
USB quick charge provides input overvoltage and undervoltage protection, output
overcurrent, overvoltage, undervoltage, short circuit protection and other functions.
The quick charge indicator light will be on when the request voltage is not 5V, that is,
when it is higher or lower than 5V.
8.
Press this button, the indicator lights will be on. All buttons and knobs except and
are disable. Press the button again and all buttons and knobs will be restored.
9. Current value adjustment knob
Press down the knob to enter the setting mode with the digit flashing. Press the knob
several times continuously to change the flashing digit. Turn the knob clockwise, the
value will increase. Turn the knob counterclockwise, the value will decrease.
10.
To Next Page
