Hanyoung PX9 series - TERMINAL ARRANGEMENT; PX Series Terminal Layouts

11
TERMINAL ARRANGEMENT
6
Note] Heater break alarm is used in option 2,3 by setting alarm outputs (AL1,AL2)
[Note] Heater break alarm is used by setting alarm outputs (AL1,AL2,AL3)
Optional Optional 1 Optional 2 Optional 3
PX9 (96 96 mm)
PX2 (48 96 mm) PX3 (96 48 mm)
PX7 (72 72 mm)
