6 are properly installed before reassembling the oil
filter cover 2.
7. Install the engine oil filter cover 2, and then screw on
the nuts 1 but not too tightly.
8. Add the specified new engine oil into the engine as
instructed in section “Engine oil change”.
BCAUTION
Insert one side with holes of the oil filter into the
engine and make sure the oil filter is installed at
correct position.
BCAUTION
Carefully inspect whether the engine parts that
have been dismantled and installed again suffer
any oil leakag e.
BCAUTION
It is suggested to replace the seal rings when the
engine oil filter element is replaced.
Engine oil strainer
Regularly replace the engine oil strainer as instructed
in the “TABLE OF REGULAR MAINTENANCE”. The
replacing steps are as follows.
1. Completely drain the original engine oil as instructed
in section “Engine oil replacement”.
2. Remove the bolts 1.
3. Remove the oil strainer cover 2, support 3 and
sealing gasket 4.
4. Remove the oil strainer 5 to clean and inspect it, and
replace it in case of damage.
5. Replace with a new sealing gasket 4.
6. Reassembly the oil strainer 5.
7. Reassembly the oil strainer cover 2, support 3,
sealing gasket 4 and bolts 1.
8. Add the specified new engine oil into the engine as
instructed in section “Engine oil replacement”.
BCAUTION
Carefully inspect whether the engine parts that
have been dismantled and installed again suffer
any oil leakag e.
BCAUTION
It is suggested to replace the sealing gasket when
the engine oil strainer is replaced.
