Avery
Ottoman bed
Page 3 of 8
No Qty Box
4 pcs
2 pcs
2 pcs
48 pcs
Hardware List
HARDWARE NEEDED FOR BED ASSEMBLY
D
F
B
A
C
No Qty Box
Hardware List
E 4 pcs
G
H
J
2 pcs
2 pcs
1 pc
1 pc
4
4
4
4
4
4
4
4
4
Metal connection plate
Metal plate for
fabric hand strape
Bolt sets (M8x25mm)
Bolt sets (M8x45mm)
Spanner for M8 nut
Allen Key for M8 bolts
Angle Brackets - RH
Angle Brackets - LH
Flanged lock-nuts M8
IMPORTANT OTTOMAN SAFETY WARNINGS
IMPORTANT – READ CAREFUL L Y – RETAIN FOR FUTURE REFERENCE
• You must ensure that the mattress is on the bed frame before operating the lift
mechanism – failure to do so could result in injury.
• Keep hands clear of the mechanism when opening or closing the ottoman.
• Beware of entrapment – never reach in through the mechanism to access the storage
area. Always ensure that the ottoman is FULLY opened before accessing the storage area.
• Do not exceed the maximum weight of mattress as specified in the table below:
Bed Min Weight (kg) Max Weight (kg)Bed Size
Double 20 50
King
Super King
25
25
55
60
• Use caution when operating, always use the handle when lifting.
• Note: This bed uses a pressurised mechanism.
• To be operated by adults only.
• Please ensure that children and pets are kept away from the bed when operating the lift
mechanism.
• Keep children and pets away from the storage area.
• Do not overload the internal storage base.
• Do not stand inside the internal storage area of the bed.
• Before removing the mattress secure the frame to ensure it does not open unexpectedly.
• Do not attempt to lie on the mattress when the ottoman is in the raised
position.
• When lifting the ottoman, remove all bedding except the fitted sheet.
IMPORTANT OTTOMAN SAFETY WARNINGS Cont.
