Harbinger L1402FX-USB - Mixer Specifications

16
L1402FX
-
USB Owner's Manual
MIXER SPECIFICATIONS
Parameter Condition L1402FX-USB
Frequency response Mic In to Main Out
(Trim at 0dB):
10Hz - 22kHz ±1dB
THD Mic In to Main Out,
20Hz to 20kHz
0.007%
Preamp Noise (EIN) 20 Hz to 20 kHz,
(150Ω source)
–
114dB
Residual Output Noise All level controls @ minimum
–
95dB
Common Mode Rejection Ratio (CMRR) Gain at 0dB >50dB @ 1kHz
Crosstalk Adjacent channels
–
70dB
Same channel
(stereo separation)
–
36dB
Input Gain Control Range 0dB to +50dB
Phantom Power DC +48V
Equalization Mono Channel, High ±15dB @ 12kHz
Mono Channel, Mid ±15dB @ 2.5kHz
Mono Channel, Low ±15dB @ 80Hz
Stereo Channel, High N/A
Stereo Channel, Mid N/A
Stereo Channel, Low N/A
Output Level Maximum +20dBu
Maximum Input Levels Mic +12dBu, Gain @ +10dB
Line Input +20dBu, Gain @ +10dB
2TK Input +20dBu
Input Impedance Mic Input 2.6kΩ, balanced
Line Input 20kΩ, balanced
2TK In 24kΩ, balanced
Output Impedance Main 240Ω, balanced / 120Ω, unbalanced
Ctrl Room, Aux Send 1 120Ω
2TK Output 1kΩ
Phones Output 25Ω
VU Meters 5 Segments +3, 0, –3, –7, –10dB
AC Power Requirements 3-pin AC Mini XLR connector 22 VAC × 2 @ 350mA
USB I/O Jack 1.1 connection Stereo 44.1k/16 Bit
Dimensions WxDxH (mm) 37mm x 255mm x 60mm
Weight (net) without PSU 2.60 kg
Weight (net) PSU .55 kg
Package Weight .82 kg
