Harbinger L502 - Page 14

14
5 & 8-CHANNEL
MIXERS
L502 & L802 Owner's Manual
PHANTOM
MIC IN
+48 VDC
LINE IN LINE IN LEFT (MONO) LINE IN RIGHT AUX RETURN LEFT (MONO) AUX RETURN RIGHT
PEAK
PEAK
MONO CHANNELS
1 and 2
GAIN
EQ
HIGHMID
80 12K2.5K
LOW
EQ
HIGHMID
80 12K2.5K
LOW
PAN
LEVEL
LEVEL
AUX
MAIN MIX
STEREO CHANNELS AUX RETURNS
3/4 and 5/6
L
L
R
R
PAN
AUX
AUX RETURN TO MAIN MIX
L
R
L
R
AUX SEND
HEADPHONE OUTPUT
LEFT
RIGHT
AUX RCA TO CTRL RM/ PHONES
AUX RCA TO MIX
CONTROL
ROOM/
PHONES
LEFT MAIN MIX OUT
RIGHT MAIN MIX OUT
LEFT CONTROL ROOM OUTPUTS
RIGHT
CD/AUX RCA OUT
LEFT
RIGHT
CD/AUX RCA IN
LEVEL
METER
LEFT MAIN BUS
RIGHT MAIN BUS
AUX BUS
BLOCK DIAGRAM - L802
