MIXER SPECIFICATIONS
Parameter Condition PAM 502 PAM 802 PAM1202FX
Frequency response Mic In to Main Out
(Trim at 0 dB):
10Hz - 22kHz +0 -1dB 10Hz - 22kHz +0 -1dB 10Hz - 22kHz +0 -1dB
THD Mic In to Main Out,
20Hz to 20kHz
0.008% 0.013% 0.007%
Preamp Noise (EIN) 20 Hz to 20 kHz,
(150Ω source)
-118 dB -118 dB -114 dB
Residual Output Noise All level controls @ minimum -87 dB -88dB -95dB
Common Mode Rejection
Ratio (CMRR)
Maximum Gain >50dB @ 1kHz >50dB @ 1kHz >50dB @ 1kHz
Crosstalk Adjacent channels -36dB -36dB -36dB
Same channel
(stereo separation)
-88dB -82dB -70dB
Input Gain Control Range 0 dB to +50 dB 0 dB to +50 dB 0 dB to +50 dB
Phantom Power DC +15V +48V +48V
Equalization Mono Channel, High ±15 dB @ 12 kHz ±15 dB @ 12 kHz ±15 dB @ 12 kHz
Mono Channel, Mid n/a ±15 dB @ 2.5 kHz ±15 dB @ 2.5 kHz
Mono Channel, Low ±15 dB @ 80 Hz ±15 dB @ 80 Hz ±15 dB @ 80 Hz
Stereo Channel, High n/a ±15 dB @ 12 kHz n/a
Stereo Channel, Mid n/a ±15 dB @ 2.5 kHz n/a
Stereo Channel, Low n/a ±15 dB @ 80 Hz n/a
Output Level Maximum +20 dBu +20 dBu +20 dBu
Maximum Input Levels Mic +12 dBu, Gain @ +10 dB +12 dBu, Gain @ +10 dB +12 dBu, Gain @ +10 dB
Line Input +20 dBu, Gain @ +10 dB +20 dBu, Gain @ +10 dB +20 dBu, Gain @ +10 dB
Aux RCA Input and Aux
Return
+20 dBu +20 dBu +20 dBu
Input Impedance Mic Input 2.6 kΩ, balanced 2.6 kΩ, balanced 2.6 kΩ, balanced
Line Input 20 kΩ, balanced 20 kΩ, balanced 20 kΩ, balanced
Stereo Aux Returns 20 kΩ, balanced 20 kΩ, balanced 20 kΩ, balanced
CD/Aux RCA In 24 kΩ, unbalanced 24 kΩ, unbalanced 24 kΩ, unbalanced
Output Impedance Main 240 Ω, balanced /
120 Ω, unbalanced
240 Ω, balanced /
120 Ω, unbalanced
240 Ω, balanced /
120 Ω, unbalanced
Ctrl Room, Aux Sends 120 Ω 120 Ω 120 Ω
Aux RCA Output 1 kΩ 1 kΩ 1 kΩ
Phones Output 25 Ω 25 Ω 25 Ω
VU Meters 5 Segments Clip (+18), +6, 0, -20 dB Clip (+18), +6, 0, -20 dB Clip (+18), +6, 0, -20 dB
AC Power Requirements 3-pin AC Mini XLR connector 22 VAC _ 2 @ 350mA 22 VAC _ 2 @ 350mA 22 VAC _ 2 @ 350mA
Dimensions WxDxH (mm) 152x198x60 212x255x60 304x255x60
Weight (net) without PSU 0.85 kg 1.45 kg 2.10 kg
