V2300 SERIES OWNER’S MANUAL
9
HARBINGER VARI Series V2318S
Amplifier
Inputs 2 XLR / TRS LINE input
Outputs 2 XLR line output
Power Output 600 watts RMS @ 8 Ohms / 2400 watts Peak
Volume Main volume control
Power Input
100-120 Volt ~60Hz 500W power draw
Features
Class D+ switching power design
Defeatable front LED with selectable power/limiter indication
Rear panel power and signal/clip LEDs
High precision digital crossover
Transparent, dynamic DSP limiter
Speaker
Type Active vented subwoofer
Frequency Response 35-150Hz
Max Output SPL@1M 134dB
Impedance 8 Ohm
Woofer 18˝ subwoofer
Cabinet Plywood with black Polyurea painted finish
Grille 1.5mm steel
Pole 35mm stand pole
Features
Rubber corner edge protection
(4) Easy-roll, lockable, rotating 3-inch casters
Dimensions and Weights
Unit Size 24.4 x 20.5 x 26.0 inches (without casters)
Package Size 28.3 x 24.4 x 32.1 inches
Unit Weight 86 pounds
Package Weight 99 pounds
V2318S SPECIFICATIONS
