V2408, V2410, VS12 OWNER’S MANUAL
8
HARBINGER VARI Series
V2408 V2410
Electronics
Voicing
Selectable VOICING (Normal, Floor Monitor, Sub Cut)
and Bass and Treble knobs all control the internal DSP to
customize the sound
Selectable VOICING (Normal, Floor Monitor, Sub Cut)
and Bass and Treble knobs all control the internal DSP
to customize the sound
Limiter
Transparent, dynamic DSP limiter for ideal sound quality
and system protection at maximum volume
Transparent, dynamic DSP limiter for ideal sound quality
and system protection at maximum volume
Smart Stereo
A pair of speakers can be connected for unified volume
and tone control from the first master speaker, with
optimal distribution of mono and audio signals between
both speakers
A pair of speakers can be connected for unified volume
and tone control from the first master speaker, with
optimal distribution of mono and audio signals between
both speakers
Input 1
XLR and 1/4-inch TRS balanced/unbalanced
compatible audio input with Mic/Guitar/Line Switch
and Input Gain Control
XLR and 1/4-inch TRS balanced/unbalanced
compatible audio input with Mic/Guitar/Line Switch
and Input Gain Control
Input 2
XLR and 1/4-inch TRS balanced/unbalanced
compatible audio input with Mic/Guitar/Line Switch
and Input Gain Control
XLR and 1/4-inch TRS balanced/unbalanced
compatible audio input with Mic/Guitar/Line Switch
and Input Gain Control
Input 3
Stereo Line: Left/mono and right 1/4-inch TRS balanced/
unbalanced compatible audio line inputs
Aux: 1/8-inch mini TRS unbalanced input (-10dB)
Bluetooth
®
Audio: with On/Pair and Off buttons
plus LED
Stereo Line: Left/mono and right 1/4-inch TRS
balanced/unbalanced compatible audio line inputs
Aux: 1/8-inch mini TRS unbalanced input (-10dB)
Bluetooth
®
Audio: with On/Pair and Off buttons
plus LED
Link In XLR balanced +4dBv audio input XLR balanced +4dBv audio input
Mix Out
XLR balanced +4dBv audio output XLR balanced +4dBv audio output
Power Output 400 Watts Peak, 100 Watts RMS 400 Watts Peak, 100 Watts RMS
Bass EQ Knob
+/-12dB Shelf, at 65Hz +/-12dB Shelf, at 65Hz
Treble EQ Knob
+/-12dB Shelf at 6.5kHz
+/-12dB Shelf at 6.5kHz
Volume
Volume control per channel Volume control per channel
Charging USB standard 5V charging up to 2.1 Amps USB standard 5V charging up to 2.1 Amps
Power Input 110-120V, 220-240V, 50-60Hz, 100w power draw 110-120V, 220-240V, 50-60Hz, 100w power draw
Other Features
Removable AC Power Cord Removable AC Power Cord
Front LED indicates power (white) and limiter (red), rear
LEDs indicate clipping (red) per input
Front LED indicates power (white) and limiter (red), rear
LEDs indicate clipping (red) per input , and limiter
Cabinet/Drivers
Type
8” 2-way vented design 10” 2-way vented design
Frequency Response
65-20KHz 55-20KHz
Max SPL@1M 118dB 120dB
HF Driver Compression Driver, 8 Ohm Compression Driver, 8 Ohm
LF Driver
8” Driver, 4 Ohm 10” Driver, 4 Ohm
Cabinet Polypropolene, with rubber surfaced feet Polypropolene, with rubber surfaced feet
Grille 1.2mm steel 1.2mm steel
Suspension Points
V2408 Is Not Designed For Suspension V2410 Is Not Designed For Suspension
Pole Mount 35mm stand pole with M6 screw 35mm stand pole with M6 screw
Dimensions and
Weights
Product Dimensions D: 10.1” x W: 10.25” x H: 17.25” D: 11.45” x W: 11.8” x H: 20”
Packaging Size D: 13.4” x W: 13.4” x H: 20.1” D: 15” x W: 15” x H: 22.85”
Net Weight 15.5 pounds 20 pounds
Gross Weight 19 pounds 24 pounds
V2408/V2410 SPECIFICATIONS
