Parts List A - Engine (16)
Part Description Qty
1A Gasket, Cylinder Head 1
2A Cylinder Head Cover 1
3A Cylinder Head Gasket 1
4A Tube, Breather 1
5A Bolt 4
6A Stud 1
7A Stud 1
8A Stud 2
9A Pin 2
10A Bolt, Cylinder Head 4
11A Plug, Spark 1
12A Cylinder Head 1
13A Crankcase 1
14A Sensor, Engine Oil 1
15A Gear Assy, Governor 1
16A Arm, Governor 1
17A Bolt, Drain Plug 2
18A Washer 2
19A Bearing 1
20A Seal, Oil 1
21A Washer 1
22A Pin 1
23A Bolt 2
24A Guide, Seal 1
25A Cover, Crankcase 1
26A Bearing 1
27A Seal, Oil 1
28A Gasket, Crankcase 1
29A Pin 2
30A Dipstick 1
31A Engine Oil Plug 1
32A Bolt 6
33A Crankshaft Assy. 1
34A Key 1
35A Clip, Piston Pin 2
36A Piston 1
37A Pin, Piston 1
38A Rod, Connecting 1
39A Ring, Primary 1
Part Description Qty
40A Ring, Secondary 1
41A Ring Set, Oil 1
42A Camshaft Assy. 1
43A Valve, Exhaust 1
44A Valve, Intake 1
45A Seat, Valve Spring 1
46A Retainer, Exhaust Valve 1
47A Rotator, Valve 1
48A Guide, Seal 1
49A Tappet, Valve 2
50A Lifter, Valve 2
51A Lifter Stopper Plate 1
52A Bolt, Valve Adjusting 2
53A Rocker, Valve 2
54A Nut, Valve Adjusting 2
55A Nut, Valve Lock 2
56A Spring, Valve 2
57A Starter Assy, Recoil 1
58A Bolt 3
59A Shroud 1
60A Shroud, Cylinder Body 1
61A Shield, Lower 1
62A Protector, Oil 1
63A Stop Engine Switch 1
64A Bolt 2
65A Bolt 1
66A Collar 1
67A Bolt 1
68A Bolt 4
69A Carburetor Assy. 1
70A Gasket, Air Cleaner 1
71A Gasket, Carburetor 1
72A Plate, Carb. Insulator 1
73A Gasket, Carb. Insulator 1
74A Nut 2
75A Cleaner, Air 1
76A Gasket, Exhaust Outlet 1
77A Nut 2
78A Muffler Assy. 1
Part Description Qty
79A Bolt 2
80A Intake Muffler Gasket 1
81A Intake Muffler Valve 1
82A Tank, Fuel 1
83A Strainer, Fuel 1
84A Cover, Fuel Tank 1
85A Fuel Tank Outlet 1
86A Clamp 4
87A Tube, Fuel 1
88A Bolt 1
89A Nut 2
90A Valve, One Way 1
91A Hose, Fuel Vapor 1
92A Clamp 2
93A Collector, Fuel Vapor 1
94A Clamp 1
95A Air Cleaner Hose 1
96A Clamp 1
97A Bolt 2
98A Vapor Collector Cover 1
99A Jacket, Rubber 1
100A Clip 1
101A Sleeve 1
102A Nut, Flywheel 1
103A Pulley, Starter 1
104A Impeller 1
105A Flywheel 1
106A Bolt 2
107A Coil, Ignition 1
108A Control Assy, Throttle 1
109A Spring, Governor 1
110A Rod, Governor 1
111A Throttle Return Spring 1
112A Governor Support 1
113A Bolt 2
114A Bolt, Governor Support 1
115A Nut 1
