Unpacking
When unpacking your Quick Action 8-Position Workbench, check to make sure the following parts
are included. If any parts are missing or broken, please call HARBOR FREIGHT TOOLS at
1-800-444-3353.
Parts List- Quick Action 8-Position W\orbench
Part # Description Quantity Part # Description Quantity
1 Swivel Peg 4 16 Cross Head Bolt m 8 x 45 2
2 Push Button 2 17 Spacer 9.5 mm 2
3 Cross head Bolt M8 x 65 2 18 Hex Nut 10
4 Washer 8 x 21 mm 4 19 Flat Washer 6 x 12 mm 10
5 Peg Support 2 20 Hex Bolt M6 x 58 2
6 Table Top (back) 1 21 Threaded Sliding Block 2
7 Connecting Part 2 22 Cross Head Bolt M8 x 50 2
7A Connecting Part 2 23 Table Top (front) 1
8 Cross Head Bolt M8 x 55 2 24 Tool Holder (front) 1
9 Spacer 22 mm 2 25 Tool Holder (back) 1
10 U-Frame Channel 2 26 Left Leg Stand Frame 1
11 Check Pawl 2 27 Right Leg Stand Frame 1
12 Spring 2 28 Grip 1
13 Sliding Locking Block 2 29 Hex Bolt M 6 x 35 8
14 Hex Nut M 8 4 30 Rubber Feet 4
15 Flat Washer 8 x 16 mm 4
Note: Some parts are listed and shown for illustration purposes only and are not available
individually as replacement parts.
#47078 Page 6
REV 01/05
