SSaaffeettyy CCaarrttrriiddggee
This safety cartidge is located in the air filter After
ffiivvee
air cleaner service or after
ttwwoo
years at the latest,
replace safety cartridge (never clean).
- Take off hood and extract the air filter
- Extract the safety cartridge and install a new one
- Replace air filter and hood
Never clean safety cartridge. Always install a new
cartridge
DDrraaiinniinngg CCoooolliinngg SSyysstteemm
ALPHA PLUS HARDI NOVA
MM AA II NN TT EE NN AA NN CC EE
CHAPTER
55-
7
- Unscrew drain plug
((22))
fully and remove drain plug from crankcase
((33))
- Drain off the coolant
- Rinse the cooling circuit with pure water
- Open the radiator cap
((44))
and fill coolant up to maximum
- Close radiator cap
((44))
, then open the expansion tank
((55))
- Add coolant (see chapter 5 ‘Coolant Level’)
- Start and run the engine up to normal operating temperature to open the thermostat housing.
- Check level and add coolant if necessary
- Open the heater valve in cab to circulate coolant in the circuit
- Check coolant level and top up as required
Capacity :
2200
l approx.
Use only cooling system protective liquid : reference TOTAL ORGANICOOL (See table of
lubricants).To prevent engine overheating (caused by sedimentation in the cooling system) do not
mix with other coolants
- Open the heater valve
in cab
((11))
33
11
44
22
55
Capacity :
2200
l approx.
