MODEL SPECIFICATIONS
1
V-Rod muScle
®
VRSCF
dimensions
Length 94.9 in. (2410 mm)
Overall Width 37.4 in. (950 mm)
Overall Height 41.9 in. (1065 mm)
Seat Height:
• Laden
2
• Unladen
25.6 in. (650 mm)
27.8 in. (705 mm)
Ground Clearance 4.1 in.
(105 mm)
Rake (steering head) 34°
Fork Angle 34°
Trail 5.6 in. (142 mm)
Wheelbase 66.9 in. (1700 mm)
Tires (Michelin
®
Scorcher
®
“11” front and rear):
• Front – Scorcher
®
“11”
• Rear – Scorcher
®
“11”
120/70ZR-19 60W
240/40R-18 79V
Fuel Capacity
5 gal. (18.9 L)
(warning light at approximately 0.5 gal.)
Oil Capacity (w/filter) 5 qts. (4.7 L)
Coolant Capacity 2.5 qts. (2.4 L)
Weight:
• As Shipped
• In Running Order
• Gross Vehicle Weight
Rating
• Gross Axle Weight
Rating
• Front
• Rear
640 lbs. (290 kg)
673 lbs. (305 kg)
1075 lbs. (488 kg)
377 lbs. (171 kg)
698 lbs. (317 kg)
engine
Engine Liquid-cooled, Revolution
®
, 60° V-Twin
Valves Overhead cam, 4 valves per cylinder,
solid tappet with shim-under-bucket
lash adjustment
Bore x Stroke 4.13 in. x 2.835 in.
(105 mm x 72 mm)
Displacement 76.1 cu. in.
(1247 cc)
Compression Ratio 11.5:1
Fuel System
3
Electronic Sequential Port Fuel Injection
(ESPFI)
Air Cleaner Down draft intake
Lubrication System Wet-sump, integrated with
powertrain crankcase
drivetrain
Primary Drive Gear, 64/117 ratio
Final Drive Belt, 28/72 ratio
Clutch 9-plate, wet, A&S (Assist & Slip)
Transmission 5-speed
Gear Ratios (overall):
• 1st
• 2nd
• 3rd
• 4th
• 5th
U.S.
11.752
7.897
6.322
5.459
4.889
chassis
Frame Steel perimeter upper frame with
hydroformed main rails and bolt-on
lower frame rails; MIG welded
Swingarm Polished, one-piece cast aluminum
Front Forks 43 mm Inverted
Rear Shocks Preload adjustable
Wheels
4
: Black 5-Spoke Cast Aluminum
• Front
• Rear
19 in. x 3 in. (483 mm x 76 mm)
18 in. x 8 in. (457 mm x 203 mm)
Brakes:
• Caliper Type
• Rotor Type
(diameter x width):
• Front
(dual)
• Rear
• Anti-lock Braking
System
4-piston front and rear
Patented, one-piece floating rotor
(front),
uniform expansion rotor
(rear)
11.81 in. x .2 in. (300 mm x 5.1 mm)
11.81 in. x .28 in. (300 mm x 7.1 mm)
Standard
Suspension Travel:
• Front Wheel
• Rear Wheel
4 in. (102 mm)
2.9 in. (74 mm)
performance
Engine Torque
5
(per J1349):
• North America 87 ft. lbs. @ 6750 RPM
(118 Nm @ 6750 RPM)
Lean Angle
(per J1168):
• Right
• Left
32°
32°
Fuel Economy
6
(EPA urban/highway test)
37 mpg (6.3 L/100 km)
electric
Battery (per Battery Council
International Rating)
Sealed, maintenance-free, 12V,
19-amp/hour, 270 cca
Charging Three-phase, 38-amp system
(439W @
13V, 2000 RPM, 489W max power @ 13V)
Starting 0.08 kW electric with direct drive
starter motor engagement
Lights
(as per country regulation):
• Headlamp
(quartz halogen)
55-watt low beam,
65-watt high beam
• Lights, Turn Signal
• Rear Tail/Stop/Turn
Signal Lights
• Indicator Lamps
Integrated LED
Integrated Dual Color LED
High beam, neutral, low oil pressure,
turn signals, engine diagnostics,
security system
7
(optional), coolant
temperature, low fuel warnings
warranty
Warranty
8
24 months (unlimited mileage)
Service Interval
9
First 1000 miles (1600 km), every
5000 miles (8000 km) thereafter
1
Vehicles depicted may differ from vehicles manufactured and delivered. Specifications and
prices listed may differ from specifications and prices of vehicles manufactured and delivered.
All product descriptions (including depictions, specifications, dimensions, measurements, ratings
and competitive comparisons) are based on available information at the time of publication.
Although such descriptions are believed correct, errors and changes can occur and complete
accuracy cannot be guaranteed. Harley-Davidson may make changes at any time to prices and
specifications, and may change or discontinue models, without notice and without incurring any
obligation. Attention: Vehicles in the configurations shown and many of the accessories described
in this catalog may not be available for sale or use in some locations. Please check with your
dealer for complete product details and the latest information. All models feature 6-speed
transmission (V-Rod
®
models and Sportster
®
models are 5-speed) and carbon fiber belt final
drive; multi-plate clutch with diaphragm spring in oil bath; and 2-year unlimited mileage warranty.
2
Measurement reflects 180 lb. (81.7 kg) operator weight.
3
Recommended 91 octane or higher fuel (R+M)/2.
4
Standard and optional wheels may vary by country and region.
5
Values shown are nominal. Performance may vary by country and region.
6
The combined fuel economy numbers were derived using a combination of estimated city and
highway values. Fuel economy estimates are derived from US EPA exhaust emission certification
data on a sample motorcycle from the corresponding family under ideal laboratory conditions.
Your actual fuel economy will vary depending on your personal riding habits, road and driving
conditions, vehicle condition and maintenance, tire pressure, vehicle configuration (parts and
accessories), and vehicle loading (cargo, rider and passenger weight). Break-in mileage may vary.
7
North America security system includes immobilizer; outside North America the security system
includes immobilizer and siren.
8
See motorcycle owner’s manual for complete details.
9
Inspections of certain systems and components are required at 2,500 mile (4,000 km) intervals.
See Owner’s Manual for full details.
