MODEL SPECIFICATIONS
1
Switchback
™
FLD
Dimensions
Length 92.9 in. (2360 mm)
Overall Width 36.6 in. (930 mm)
Overall Height 54.5 in. (1385 mm)
Seat Height:
• Laden
2
• Unladen
26.1 in.
(663 mm)
27.4 in.
(695 mm)
Ground Clearance 4.3 in.
(110 mm)
Rake (steering head) 29.9°
Fork Angle 28.9°
Trail 5.84 in. (148.3 mm)
Wheelbase 62.8 in. (1595 mm)
Tires (Dunlop
®
Harley-Davidson
®
Series, bias blackwall front and rear):
• Front – Dunlop
®
D402F
• Rear – Dunlop
®
D401
130/70B18 63H
160/70B17 73H
Fuel Capacity
4.7 gal. (17.8 L)
(warning light at approximately 0.9 gal.)
Oil Capacity (w/filter) 3 qts. (2.8 L)
Transmission Capacity 1 qt. (.95 L)
Primary Chain
Case Capacity
1 qt. (.95 L)
Weight:
• As Shipped
• In Running Order
• Gross Vehicle
Weight Rating
• Gross Axle
Weight Rating:
• Front
• Rear
696 lbs. (316 kg)
718 lbs. (326 kg)
1170 lbs. (530 kg)
455 lbs. (206 kg)
794 lbs. (360 kg)
enGine
Engine
Air-cooled, Twin Cam 103
™
Valves Pushrod- operated, overhead valves
with hydraulic, self adjusting lifters;
two valves per cylinder
Bore x Stroke 3.87 in. x 4.374 in.
(98.4 mm x 111.1 mm)
Displacement 103.1 cu. in.
(1690 cc)
Compression Ratio 9.6:1
Fuel System
3
Electronic Sequential Port Fuel Injection
(ESPFI)
Air Cleaner Fiberglass media, washable
Lubrication System Pressurized, dry-sump
Drivetrain
Primary Drive Chain, 34/46 ratio
Final Drive Belt, 32/66 ratio
Clutch Multi-plate, wet
Transmission
6-speed Cruise Drive
®
Gear Ratios (overall):
• 1st
• 2nd
• 3rd
• 4th
• 5th
• 6th
U.S.
9.311
6.454
4.793
3.882
3.307
2.79
chassis
Frame Mild steel, tubular frame; rectangular
section backbone; stamped, cast,
and forged junctions; forged fender
supports; MIG welded
Swingarm Mild steel, rectangular tube
sections backbone; stamped
junctions; MIG welded
Front Forks 41.3 mm fork with 20 mm cartridge
damping and triple rate spring
Rear Shocks Nitrogen charged 36 mm monotube
damper with 5 step preload adjustable
dual rate spring
Wheels
4
: Black 5-Spoke Cast Aluminum
• Front
• Rear
18 in. x 3.5 in. (457 mm x 89 mm)
17 in. x 4.5 in. (432 mm x 114 mm)
Brakes:
• Caliper Type
• Rotor Type
(diameter x width):
• Front
(floating)
• Rear
• Anti-lock Braking
System
4-piston fixed front, and 2-piston
torque-free floating rear
Patented, uniform expansion rotors
(floating, front only)
11.8 in. x .2 in. (300 mm x 5.1 mm)
11.5 in. x .2 in. (292 mm x 5.1 mm)
Standard
Suspension Travel:
• Front Wheel
• Rear Wheel
3.86 in. (98 mm)
2.13 in. (54 mm)
performance
Engine Torque
5
(per J1349):
• North America 98.8 ft. lbs. @ 3500 RPM
(134 Nm @ 3500 RPM)
Lean Angle
(per J1168):
• Right
• Left
29°
29°
Fuel Economy
6
(EPA urban/highway test)
42 mpg (5.6 L/100 km)
electric
Battery (per Battery Council
International Rating)
Sealed, maintenance-free, 12V,
19-amp/hour, 270 cca
Charging Three-phase, 40-amp system
(493W @
13.5V, 2000 RPM, 540W max power @ 13.5V)
Starting 1.2kW electric with solenoid shift starter
motor engagement
Lights
(as per country regulation):
• Headlamp
(quartz halogen)
55-watt low beam,
60-watt high beam
• Tail/Stop Lights
• Turn Signal Lights
• Indicator Lamps
8W/28W
28W self-canceling
High beam, neutral, low oil pressure,
engine diagnostics, turn signals,
low fuel warning, ABS
(optional), low
battery, body controller diagnostics
warranty
Warranty
8
24 months (unlimited mileage)
Service Interval
9
First 1000 miles (1600 km), every
5000 miles (8000 km) thereafter
1
Vehicles depicted may differ from vehicles manufactured and delivered. Specifications and
prices listed may differ from specifications and prices of vehicles manufactured and delivered.
All product descriptions (including depictions, specifications, dimensions, measurements, ratings
and competitive comparisons) are based on available information at the time of publication.
Although such descriptions are believed correct, errors and changes can occur and complete
accuracy cannot be guaranteed. Harley-Davidson may make changes at any time to prices and
specifications, and may change or discontinue models, without notice and without incurring any
obligation. Attention: Vehicles in the configurations shown and many of the accessories described
in this catalog may not be available for sale or use in some locations. Please check with your
dealer for complete product details and the latest information. All models feature 6-speed
transmission (V-Rod
®
models and Sportster
®
models are 5-speed) and carbon fiber belt final
drive; multi-plate clutch with diaphragm spring in oil bath; and 2-year unlimited mileage warranty.
2
Measurement reflects 180 lb. (81.7 kg) operator weight.
3
Recommended 91 octane or higher fuel (R+M)/2.
4
Standard and optional wheels may vary by country and region.
5
Values shown are nominal. Performance may vary by country and region.
6
The combined fuel economy numbers were derived using a combination of estimated city and
highway values. Fuel economy estimates are derived from US EPA exhaust emission certification
data on a sample motorcycle from the corresponding family under ideal laboratory conditions.
Your actual fuel economy will vary depending on your personal riding habits, road and driving
conditions, vehicle condition and maintenance, tire pressure, vehicle configuration (parts and
accessories), and vehicle loading (cargo, rider and passenger weight). Break-in mileage may vary.
8
See motorcycle owner’s manual for complete details.
9
Inspections of certain systems and components are required at 2,500 mile (4,000 km) intervals.
See Owner’s Manual for full details.
