22
INSTALLATION
NOTE: It’s possible for a source to use none of the connections
named for that source. For example, you might connect your
DVD player to the Component Video 1 inputs and the Coax 1
digital audio input. However, we will refer to this source as
“DVD,” and in the Initial Setup section you will program the
receiver so that these connections are assigned to the DVD
source. When you select “DVD” as your source using the front
panel or the remote, the correct connections for your DVD
player will be used.
We recommend connecting your various sources using the connections
shown in Table 2 (below) in order to simplify programming your receiver
and remote control. However, you may connect any device to any
source input.
Device Type AVR 245 Source Input Audio Connections Video Connections
VCR, DVR, PVR, Video 1 • Video 1 Analog (inputs and outputs) •
One
of component Video 2, Video 1 S-video
TiVo or other and
or
Video 1 composite video
audio/video recorder • Any one available coaxial or optical digital, • For recording, use Video 1 S-video
or
audio input, with corresponding coax composite video output, and do not use
or optical digital output component video connections at all
Cable TV, satellite TV, Video 2 • Video 2 Analog and •
One
of component Video 3, Video 2
HDTV or other • Optical 1 S-video
or
Video 2 composite video
device that delivers
television programs
TV or other Video 3 • Video 3 Analog and • Video 3 S-video
or
Video 3 composite
audio/video device • Any one available coaxial or optical video
digital audio input
TV, game console, Video 4 (front-panel jacks) • Video 4 Analog and • Video 4 S-video
or
Video 4 composite video
camera or other •
Either
Coax 3
or
Optical 3
audio/video device
DVD Audio/Video, DVD • DVD Analog • Component Video 1
SACD, HD-DVD, • 6-/8-Channel inputs (optional) and
Blu-ray Disc • Coax 1
HDMI-capable DVD HDMI 1 • Coaxial 2 digital audio input • HDMI 1 Input
player or other audio/
video device
HDMI-capable DVD HDMI 2 • Optical 2 digital audio input • HDMI 2 Input
player or other audio/
video device
CD player CD • CD Analog and • Not required
• Any one available coaxial or optical
digital audio input
CDR, MiniDisc, Tape • Tape Analog (inputs and outputs) and • Not required
cassette • Any one available coaxial or optical digital,
audio input, with corresponding coax
or optical digital output
Table 2 – Recommended Source Component Connections
HKP1477AVR245om 8/29/06 5:46 PM Page 22
