Harman Kardon AVR 254 User Manual

13
13
13
13
FM Antenna
XM
Antenna
AM Antenna
S-Video 2 Output
Composite 2 Output
Composite 1, 2 and 3
S-Video 1, 2 and 3
Video Monitor Outputs
HDMI 1, 2 and 3
AC Power Cord
Component 1 and 2
Stereo Jack
HDMI Monitor Output
Component Video Monitor Outputs
Subwoofer Output
Preamp Outputs
Front Speaker Outputs
Surround Speaker Outputs
6-/8- Channel Inputs
Surround Back/Zone 2 Speaker Outputs
Center Speaker Outputs
Switched AC Accessory Outlet
RS-232 Reset
RS-232 Serial Port
Coaxial Digital Audio Output
Coaxial 1 and 2 Digital Audio
Optical 1 and 2 Digital Audio
Analog 1-5 Inputs
Zone 2 IR Input
Remote IR Input
Remote IR Output
Analog 2 Outputs
Analog 4 Outputs
RS-232 Mode
NOTE: To make it easier to follow the instructions throughout the manual that refer to this illustration, a copy of this page may be downloaded from the Product Support section at
www.harmankardon.com. All connectors are inputs except as indicated.
