Harman Kardon AVR 254

9
Resolution
Source List
Navigation
Video Modes
OK
Back/ Exit
Navigation
Headphone Jack/EzSet/EQ Microphone Input
Digital Audio Inputs (Optical 3 and Coaxial 3)
Video 4 Video Inputs
Video 4 Analog Audio Inputs
Surround Modes
Audio Effects
AVR Info
Power Indicator
Main Power Switch
Standby/On Switch
Volume
Message Display
Speaker/Channel Input Indicators
Remote IR Sensor
/
/
NOTE: To make it easier to follow the instructions throughout the manual that refer to this illustration, a copy of this page may be downloaded from the Product Support section at
www.harmankardon.com.
