Harman Kardon AVR 2550 User Manual

FUNCTION LIST 33
Function List
No. Button Name Tape VCR (VID 1) TV (VID 2) CBL SAT
1 Power On Power On Power On Power On Power On Power On
2 Power Off Power Off Power Off Power Off Power Off Power Off
3 Mute Mute
4 AVR
5 DVD
6 CD
7 Tape Tape Select
8 VID 1 VCR Select
9 VID 2 TV Select
10 CBL/SAT CBL/SAT Select CBL/SAT Select
11 AM/FM
12 Sleep Channel + Channel + Channel + Channel +
13 Test
14 TV TV/VCR TV/VCR TV/Cable TV/Sat
15 Volume Up Volume Up Volume Up
16 Surround Select Channel – Channel – Channel –
17 Night
18 Spare
19 Volume Down Volume Down
20 Channel/Guide Info/Guide Info/Guide
21
⁄
Up Up Up Up
22 Speaker/Menu Menu Menu Menu Menu
23 fi Left Left Left Left
24 Set Enter Enter Enter Enter
25 fl Right Right Right Right
26 Digital/Exit Exit Exit Exit Exit
27 ¤ Down Down Down Down
28 Delay/Prev. Ch. Prev Channel Prev Channel Prev Channel
29 1 1111
30 2 2222
31 3 3333
32 4 4444
33 5 5555
34 6 6666
35 7 7777
36 8 8888
37 Tun-M
38 9 9999
39 0 0000
40 Memory
41 Tune Up
42 Direct
43 Clear Clear Clear Clear Clear
44 Preset Up
45 Tune Down
46 RDS
47 Preset Down
48 M1 Cancel Sleep PPV Cancel
49 M2 Fav Fav
50 M3 Bypass Next
51 M4 Music Alt
52 Rewind Rewind Rewind Day – Say –
53 Play Play Play
54 Fast Forward Fast Fwd Fast Fwd Day + Day +
55 Record Record/Rec.Pause Record
56 Stop Stop Stop
57 Pause Pause
58 Skip Down Scan – Page – Page –
59 Skip Up Scan + Page + Page +

Harman Kardon AVR 2550 Specifications

Audio Specifications

continuous average power (stereo mode)	50 watts per channel into 8 ohms @ 20Hz – 20kHz, <0.07% THD, both channels driven
continuous average power (five-channel surround mode)	40 watts per channel into 8 ohms @ 20Hz – 20kHz, <0.07% THD, all channels driven
high instantaneous current capability (HCC)	±25 amps

Tuner Specifications

usable sensitivity	IHF 1.3µV/13.2dBf
THD at 1kHz with 100% modulation (mono)	0.15%
THD at 1kHz with 100% modulation (stereo)	0.3%

Weight and Dimensions

dimensions (H x W x D)	165mm x 440mm x 365mm
weight	10.8 kg
