Harman Kardon AVR 360 Service Manual

Level Ref. # Part Numbe
r
Description
Drawin
g
No
(
Value
)
Qt
y
UM
....5 D401 CVD1N4003ST DIODE , RECT 1N4003 1 EA
....5 D412 HVDMTZJ6.8BT DIODE , ZENER MTZJ6.8B 1/2W 1 EA
....5 D413 HVDMTZJ27BT DIODE , ZENER MTZJ27B 1/2W 1 EA
....5 D421 HVDMTZJ6.8BT DIODE , ZENER MTZJ6.8B 1/2W 1 EA
....5 D422 HVDMTZJ6.8BT DIODE , ZENER MTZJ6.8B 1/2W 1 EA
....5 D455 CVD1SS133MT DIODE 1SS133 1 EA
....5 D531 CVD1SS133MT DIODE 1SS133 1 EA
....5 D534 CVD1SS133MT DIODE 1SS133 1 EA
....5 D631 CVD1SS133MT DIODE 1SS133 1 EA
....5 D632 CVD1SS133MT DIODE 1SS133 1 EA
....5 D633 CVD1SS133MT DIODE 1SS133 1 EA
....5 D634 CVD1SS133MT DIODE 1SS133 1 EA
....5 L151 HLQ02C100KT COIL , AXAIL (10UH) 1 EA
....5 Q104 CVTKTC1027YT T.R 1EA
....5 Q111 HVTKRA107MT T.R KRA107M 1 EA
....5 Q112 HVTKRC107MT T.R KRC107M 1 EA
....5 Q113 HVTKRC107MT T.R KRC107M 1 EA
....5 Q251 HVTKTA1271YT T.R KTA1271Y 1 EA
....5 Q252 HVTKRC107MT T.R KRC107M 1 EA
....5 Q721 HVTKRC107MT T.R KRC107M 1 EA
....5 Q941 HVTKTC2874BT T.R , MUTE KTC2874B 1 EA
....5 Q942 HVTKTC2874BT T.R , MUTE KTC2874B 1 EA
....5 Q943 HVTKTC2874BT T.R , MUTE KTC2874B 1 EA
....5 Q944 HVTKTC2874BT T.R , MUTE KTC2874B 1 EA
....5 Q951 HVTKRC107MT T.R KRC107M 1 EA
....5 Q952 HVTKRA107MT T.R KRA107M 1 EA
....5 Q954 HVTKRC107MT T.R KRC107M 1 EA
....5 R101 CRD20TF2200T RES , CARBON(220 OHM, 1%) 1 EA
....5 R102 CRD20TF6800T RES , CARBON(680 OHM, 1%) 1 EA
....5 R113 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1 EA
....5 R121 CRD20TJ473T RES , CARBON 47K OHM 1/5W J 1 EA
....5 R122 CRD20TJ100T RES , CARBON 10 OHM 1/5W J 1 EA
....5 R201 CRD20TJ101T RES , CARBON(1/5W,100,5%) 100 OHM 1/5W J 1 EA
....5 R202 CRD20TJ101T RES , CARBON(1/5W,100,5%) 100 OHM 1/5W J 1 EA
....5 R203 CRD20TJ101T RES , CARBON(1/5W,100,5%) 100 OHM 1/5W J 1 EA
....5 R211 CRD20TJ101T RES , CARBON(1/5W,100,5%) 100 OHM 1/5W J 1 EA
....5 R213 CRD20TJ272T RES , CARBON 2.7K OHM 1/5W J 1 EA
....5 R214 CRD20TJ272T RES , CARBON 2.7K OHM 1/5W J 1 EA
....5 R251 CRD20TJ222T RES , CARBON 2.2K OHM 1/5W J 1 EA
....5 R252 CRD25TJ393T RES , CARBON (39K OHM) 1 EA
....5 R312 CRD20TF1001T RES , CARBON 1K /1/5W /F 1 EA
....5 R313 CRD20TF1501T RES , CARBON 1.5K /1/5W /F 1 EA
....5 R314 CRD20TF1801T RES , CARBON 1.8K /1/5W /F 1 EA
....5 R315 CRD20TF2701T RES , CARBON 2.7K /1/5W/F 1 EA
....5 R316 CRD20TF3301T RES , CARBON 3.3K /1/5W/F 1 EA
....5 R322 CRD20TF1001T RES , CARBON 1K /1/5W /F 1 EA
....5 R323 CRD20TF1501T RES , CARBON 1.5K /1/5W /F 1 EA
....5 R324 CRD20TF1801T RES , CARBON 1.8K /1/5W /F 1 EA
....5 R325 CRD20TF2701T RES , CARBON 2.7K /1/5W/F 1 EA
....5 R326 CRD20TF3301T RES , CARBON 3.3K /1/5W/F 1 EA
....5 R327 CRD20TF5601T RES , CARBON(5.6K/F) 1 EA
....5 R328 CRD20TF5601T RES , CARBON(5.6K/F) 1 EA
....5 R401 CRD25FJ3R3T RES , CARBON 3.3 OHM 1/4W J 1 EA
....5 R402 CRD25TJ5R6T RES , CARBON (5.6 OHM) 1 EA
....5 R403 CRD20TJ100T RES , CARBON 10 OHM 1/5W J 1 EA
....5 R404 CRD25TJ5R6T RES , CARBON (5.6 OHM) 1 EA
....5 R411 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1 EA
....5 R412 CRD20TJ122T RES , CARBON 1.2K OHM 1/5W J 1 EA
....5 R413 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1 EA
....5 R415 CRD20TJ473T RES , CARBON 47K OHM 1/5W J 1 EA
....5 R431 CRD20TJ100T RES , CARBON 10 OHM 1/5W J 1 EA
....5 R432 CRD20TJ100T RES , CARBON 10 OHM 1/5W J 1 EA
....5 R511 CRD20TJ100T RES , CARBON 10 OHM 1/5W J 1 EA
....5 R512 CRD20TJ100T RES , CARBON 10 OHM 1/5W J 1 EA
....5 R513 CRD20TJ153T RES , CARBON 15K OHM 1/5W J 1 EA
....5 R514 CRD20TJ153T RES , CARBON 15K OHM 1/5W J 1 EA
....5 R541 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1 EA
....5 R551 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1 EA
....5 R552 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1 EA
....5 R553 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1 EA
....5 R554 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1 EA
....5 R601 CRD20TJ750T RES , CARBON 75 OHM 1/5W J 1 EA
....5 R603 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1 EA
....5 R604 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J 1 EA
....5 R612 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1 EA
....5 R701 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1 EA
....5 R702 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1 EA
....5 R703 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1 EA
....5 R711 CRD20TJ470T RES , CARBON 47 OHM 1/5W J 1 EA
....5 R712 CRD20TJ470T RES , CARBON 47 OHM 1/5W J 1 EA
....5 R713 CRD20TJ470T RES , CARBON 47 OHM 1/5W J 1 EA
....5 R721 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1 EA
....5 R722 CRD20TJ101T RES , CARBON(1/5W,100,5%) 100 OHM 1/5W J 1 EA
....5 R731 CRD20TJ100T RES , CARBON 10 OHM 1/5W J 1 EA
....5 R735 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1 EA
FRONT PCB ASS
Y
harman/kardon
AVR 360/230 Service Manual
Page 15 of 138

Harman Kardon AVR 360 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.07 %
Power output per channel (1KHz@6 Ohm)	130 W
Power output per channel (20-20KHz@8 Ohm)	55 W
Headphone outputs	1
Headphone connectivity	-
HDMI in	4
Digital audio optical in	3
Product color	Black, Silver
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
Handheld remote control	No
Apple docking compatibility	Not supported
Connectivity technology	Wired
Supported radio bands	AM, FM
Preset stations quantity	30

Weight and Dimensions

Depth	382 mm
Width	440 mm
Height	165 mm
Weight	13400 g
