Harman Kardon AVR 360 Service Manual

Level Ref. # Part Numbe
r
Description
Drawin
g
No
(
Value
)
Qt
y
UM
....5 R741 CRD20TJ123T RES , CARBON 12K OHM 1/5W J 1 EA
....5 R742 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1 EA
....5 R801 CRD20TJ101T RES , CARBON(1/5W,100,5%) 100 OHM 1/5W J 1 EA
....5 R802 CRD20TJ101T RES , CARBON(1/5W,100,5%) 100 OHM 1/5W J 1 EA
....5 R811 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1 EA
....5 R812 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1 EA
....5 R813 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1 EA
....5 R821 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1 EA
....5 R822 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1 EA
....5 R823 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1 EA
....5 R834 CRD20TJ222T RES , CARBON 2.2K OHM 1/5W J 1 EA
....5 R835 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1 EA
....5 R836 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1 EA
....5 R901 CRD25TJ101T RES , CARBON (100 OHM) 1 EA
....5 R902 CRD20TJ101T RES , CARBON(1/5W,100,5%) 100 OHM 1/5W J 1 EA
....5 R911 CRD20TJ101T RES , CARBON(1/5W,100,5%) 100 OHM 1/5W J 1 EA
....5 R912 CRD20TJ101T RES , CARBON(1/5W,100,5%) 100 OHM 1/5W J 1 EA
....5 R921 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1 EA
....5 R922 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1 EA
....5 R923 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1 EA
....5 R924 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J 1 EA
....5 R925 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1 EA
....5 R926 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1 EA
....5 R931 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1 EA
....5 R932 CRD20TJ104T RES , CARBON 100K OHM 1/5W J 1 EA
....5 R933 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1 EA
....5 R934 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1 EA
....5 R935 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1 EA
....5 R936 CRD20TJ221T RES , CARBON 220 OHM 1/5W J 1 EA
....5 R941 CRD25TJ432T RES , CARBON(1/4W, 4.3K) 1 EA
....5 R942 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J 1 EA
....5 R943 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J 1 EA
....5 R944 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J 1 EA
....5 R951 CRD20TJ102T RES , CARBON 1K OHM 1/5W J 1 EA
....5 R953 CRD20TJ362T RES , CARBON 3.6K OHM 1/5W J 1 EA
....5 R954 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1 EA
....5 S311 CST1A024ZT SW , TACT 1EA
....5 S312 CST1A024ZT SW , TACT 1EA
....5 S313 CST1A024ZT SW , TACT 1EA
....5 S314 CST1A024ZT SW , TACT 1EA
....5 S315 CST1A024ZT SW , TACT 1EA
....5 S316 CST1A024ZT SW , TACT 1EA
....5 S317 CST1A024ZT SW , TACT 1EA
....5 S318 CST1A024ZT SW , TACT 1EA
....5 S319 CST1A024ZT SW , TACT 1EA
....5 S320 CST1A024ZT SW , TACT 1EA
....5 S321 CST1A024ZT SW , TACT 1EA
....5 S322 CST1A024ZT SW , TACT 1EA
....5 S323 CST1A024ZT SW , TACT 1EA
....5 S330 CST1A024ZT SW , TACT 1EA
...4 BK71 CMD1A572 BRACKET , FIP 1EA
...4 BK72 CMD1A572 BRACKET , FIP 1EA
...4 BK73 CMC1A390 PLATE , SHIELD 1EA
...4 BK74 CMC1A390 PLATE , SHIELD 1EA
...4 BN51 CWB1C907400BM001 SHIELD WIRE ASS'Y (2.5mm, 400mm, 7pin) 1 EA
...4 BN52 CWB1C903400BM001 SHIELD WIRE ASS'Y (2.5mm, 400mm, 3pin) 1 EA
...4 BN61 CJP12GB143ZB PIN HEADER , DIP SOCKET(12PIN, 2.54mm, ANGLE) 1 EA
...4 BN73 CJP06GB143ZB FEMALE HEADER(6P, 2.54mm) 1 EA
...4 BN74 CWB1C905120BM WIRE ASS'Y 1EA
...4 CN61 CJP12GA239ZB PIN HEADER(12P, 2.54mm), STRAIGHT TYPE 1 EA
...4 CN71 CJP05GB03ZY WAFER , ANGLE (2.5mm) 1 EA
...4 CN72 CJP31GA41ZM WAFER
(
1.25MM, CARD CABLE, STRAIGHT 3
1
MOLEX 52045-**45 1 EA
...4 CN73 CJP06GB142ZB PIN HEADER(6P, 2.54mm) 1 EA
...4 CN74 CJP05GB03ZY WAFER , ANGLE (2.5mm) 1 EA
...4 C411 CCEA1JH101E CAP , ELECT 100UF 63V 1 EA
...4 D101 CVD1L0345W31BOCT201W L.E.D , WHITE 1EA
...4 D102 CVD30ASOGCAA-S7 L.E.D , ORANGE T0L-30ASOGCAA-S7 1 EA
...4 D201 CVD1L0345W31BOCT201W L.E.D , WHITE 1EA
...4 D202 CVD1L0345W31BOCT201W L.E.D , WHITE 1EA
...4 D203 CVD1L0345W31BOCT201W L.E.D , WHITE 1EA
...4 ET63 CMC2A325 PLATE , EARTH AVR155 1 EA
...4 ET64 CMC4A111 PLATE , EARTH 1EA
...4 FB13 KLZ9H001Z BEAD , CORE 1EA
...4 FB14 KLZ9H001Z BEAD , CORE 1EA
...4 FB15 KLZ9H001Z BEAD , CORE 1EA
...4 F1 CFL162BD01GINK V.F.D 162-BD-01GINK 1 EA
...4 IC11 HVI74HCU04AFNG I.C , INVERTER (TOSHIBA) TC74HCU04AFNG(TOSHIBA) 1 EA
...4 IC12 HRVNJL34H380A SENSOR , REMOCON (JRC) 1 EA
...4 IC13 HVI74ACT04MTR I.C , HEX (ST) 1EA
...4 IC14 HVINJM2068MTE1 I.C , OP AMP (JRC) NJM2068M-TE1 1 EA
...4 IC15 HVINJM4556AL I.C , HEADPHONE (JRC) NJM4556AL 1 EA
...4 JK51 CJJ9X006Z JACK , USB STRAIGHT(BLACK) U250FD004BY 1 EA
...4 JK52 CJJ4S028Y JACK , BOARD (3P SILVER) 1 EA
...4 JK61 CJJ4M041Y JACK , BOARD (COAX) 1 EA
...4 JK62 HJSTORX177L MODULE , OPTICAL(RX) TORX177L 1 EA
FRONT PCB ASS
Y
harman/kardon
AVR 360/230 Service Manual
Page 16 of 138

Harman Kardon AVR 360 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.07 %
Power output per channel (1KHz@6 Ohm)	130 W
Power output per channel (20-20KHz@8 Ohm)	55 W
Headphone outputs	1
Headphone connectivity	-
HDMI in	4
Digital audio optical in	3
Product color	Black, Silver
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
Handheld remote control	No
Apple docking compatibility	Not supported
Connectivity technology	Wired
Supported radio bands	AM, FM
Preset stations quantity	30

Weight and Dimensions

Depth	382 mm
Width	440 mm
Height	165 mm
Weight	13400 g
