Harman Kardon AVR 360 Service Manual

Level Ref. # Part Numbe
r
Description
Drawin
g
No
(
Value
)
Qt
y
UM
...4 JK63 CJJ2E026Z JACK , HEADPHONE(SILVER PLATE) 1 EA
...4 RL91 CSL4A016ZU RELAY , 12V 2C2P BC3-12H 1 EA
...4 VR74 CSR2A037Z ENCODER 1EA
Level
Ref. # Part Numbe
r
Description
Drawin
g
No
(
Value
)
Qt
y
UM
..3 COP12170F AVR360 MAIN PCB ASS'
Y
1E
A
....5 C501 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C502 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C503 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C504 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C505 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C506 CCKT1H331KB CAP , CERAMIC 330PF 50V K 1 EA
....5 C507 CCBS1H331KBT CAP , CERAMIC(330PF/50V) CH UP025 B331K-A-B Z 1 EA
....5 C508 CCBS1H331KBT CAP , CERAMIC(330PF/50V) CH UP025 B331K-A-B Z 1 EA
....5 C509 CCKT1H331KB CAP , CERAMIC 330PF 50V K 1 EA
....5 C510 CCBS1H331KBT CAP , CERAMIC(330PF/50V) CH UP025 B331K-A-B Z 1 EA
....5 C561 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
....5 C562 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
....5 C563 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
....5 C564 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
....5 C565 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
....5 C566 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
....5 C567 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
....5 C568 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
....5 C569 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
....5 C570 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
....5 C571 CCBS1H681KBT CAP , CERAMIC(680PF/50V) CH UP025 B681K-A-B Z 1 EA
....5 C572 CCBS1H681KBT CAP , CERAMIC(680PF/50V) CH UP025 B681K-A-B Z 1 EA
....5 C573 CCBS1H681KBT CAP , CERAMIC(680PF/50V) CH UP025 B681K-A-B Z 1 EA
....5 C574 CCBS1H681KBT CAP , CERAMIC(680PF/50V) CH UP025 B681K-A-B Z 1 EA
....5 C575 CCBS1H681KBT CAP , CERAMIC(680PF/50V) CH UP025 B681K-A-B Z 1 EA
....5 C601 CCCT1H120JC CAP , CERAMIC 12PF 50V J 1 EA
....5 C602 CCCT1H120JC CAP , CERAMIC 12PF 50V J 1 EA
....5 C603 CCCT1H120JC CAP , CERAMIC 12PF 50V J 1 EA
....5 C604 CCCT1H120JC CAP , CERAMIC 12PF 50V J 1 EA
....5 C605 CCCT1H120JC CAP , CERAMIC 12PF 50V J 1 EA
....5 C606 CCCT1H330JC CAP , CERAMIC 33PF 50V J 1 EA
....5 C607 CCCT1H330JC CAP , CERAMIC 33PF 50V J 1 EA
....5 C608 CCCT1H330JC CAP , CERAMIC 33PF 50V J 1 EA
....5 C609 CCCT1H330JC CAP , CERAMIC 33PF 50V J 1 EA
....5 C610 CCCT1H330JC CAP , CERAMIC 33PF 50V J 1 EA
....5 C681 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C682 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C683 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C684 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C685 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C726 CCKT1H221KB CAP , CERAMIC 220PF 50V K 1 EA
....5 C801 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C802 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C803 CCCT1H330JC CAP , CERAMIC 33PF 50V J 1 EA
....5 C804 CCCT1H330JC CAP , CERAMIC 33PF 50V J 1 EA
....5 C805 CCCT1H120JC CAP , CERAMIC 12PF 50V J 1 EA
....5 C806 CCCT1H120JC CAP , CERAMIC 12PF 50V J 1 EA
....5 C811 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
....5 C812 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
....5 C813 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
....5 C814 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
....5 C815 CCKT1H331KB CAP , CERAMIC 330PF 50V K 1 EA
....5 C816 CCBS1H331KBT CAP , CERAMIC(330PF/50V) CH UP025 B331K-A-B Z 1 EA
....5 C817 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C818 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C819 CCBS1H681KBT CAP , CERAMIC(680PF/50V) CH UP025 B681K-A-B Z 1 EA
....5 C820 CCBS1H681KBT CAP , CERAMIC(680PF/50V) CH UP025 B681K-A-B Z 1 EA
....5 C851 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C852 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C853 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C854 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C855 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C856 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C857 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
....5 C900 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
....5 C901 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
....5 C905 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) CH UP025 F223Z-A-B J 1 EA
....5 C907 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
....5 C908 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) CH UP025 F223Z-A-B J 1 EA
....5 C910 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
....5 C911 CCEA1CH471T CAP , ELECT 470UF 16V 1 EA
....5 C912 CCEA1CH221T CAP , ELECT 220UF 16V 1 EA
....5 C913 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V Z 1 EA
....5 C914 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
....5 C917 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
....5 C918 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
....5 C919 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
....5 C924 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V Z 1 EA
FRONT PCB ASS
Y
MAIN PCB ASS
Y
harman/kardon
AVR 360/230 Service Manual
Page 17 of 138

Harman Kardon AVR 360 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.07 %
Power output per channel (1KHz@6 Ohm)	130 W
Power output per channel (20-20KHz@8 Ohm)	55 W
Headphone outputs	1
Headphone connectivity	-
HDMI in	4
Digital audio optical in	3
Product color	Black, Silver
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
Handheld remote control	No
Apple docking compatibility	Not supported
Connectivity technology	Wired
Supported radio bands	AM, FM
Preset stations quantity	30

Weight and Dimensions

Depth	382 mm
Width	440 mm
Height	165 mm
Weight	13400 g
