Harman Kardon AVR 360 Service Manual

Level Ref. # Part Numbe
r
Description
Drawin
g
No
(
Value
)
Qt
y
UM
....5 C932 CCEA1CH101T CAP , ELECT 100UF 16V 1 EA
....5 C933 CCEA1EH221T CAP , ELECT 220UF 25V 1 EA
....5 C934 CCFT1H223ZF CAP , CERAMIC 0.022UF 50V Z 1 EA
....5 C936 CCEA1EH221T CAP , ELECT 220UF 25V 1 EA
....5 C939 CCEA1HH4R7T CAP , ELECT 4.7UF 50V 1 EA
....5 C940 CCEA1AH471T CAP , ELECT 470UF 10V 1 EA
....5 C948 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
....5 C950 CCEA1AH471T CAP , ELECT 470UF 10V 1 EA
....5 C971 HCQI1H562JZT CAP , MYLAR 5600PF 50V J 1 EA
....5 C972 HCQI1H562JZT CAP , MYLAR 5600PF 50V J 1 EA
....5 C973 HCQI1H562JZT CAP , MYLAR 5600PF 50V J 1 EA
....5 C974 HCQI1H562JZT CAP , MYLAR 5600PF 50V J 1 EA
....5 C975 HCQI1H562JZT CAP , MYLAR 5600PF 50V J 1 EA
....5 C977 CCEA1HH4R7T CAP , ELECT 4.7UF 50V 1 EA
....5 C980 HCQI1H562JZT CAP , MYLAR 5600PF 50V J 1 EA
....5 C981 HCQI1H562JZT CAP , MYLAR 5600PF 50V J 1 EA
....5 C990 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
....5 C991 CCEA1HH1R0T CAP , ELECT 1UF 50V 1 EA
....5 C992 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
....5 C993 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
....5 C994 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
....5 C995 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
....5 C996 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
....5 C997 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J 1 EA
....5 C999 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) CH UP025 F223Z-A-B J 1 EA
....5 D501 HVD1SS133MT DIODE 1SS133T-77 1 EA
....5 D502 HVD1SS133MT DIODE 1SS133T-77 1 EA
....5 D503 HVD1SS133MT DIODE 1SS133T-77 1 EA
....5 D504 HVD1SS133MT DIODE 1SS133T-77 1 EA
....5 D505 HVD1SS133MT DIODE 1SS133T-77 1 EA
....5 D581 HVD1SS133MT DIODE 1SS133T-77 1 EA
....5 D582 HVD1SS133MT DIODE 1SS133T-77 1 EA
....5 D583 HVD1SS133MT DIODE 1SS133T-77 1 EA
....5 D584 HVD1SS133MT DIODE 1SS133T-77 1 EA
....5 D585 HVD1SS133MT DIODE 1SS133T-77 1 EA
....5 D801 HVD1SS133MT DIODE 1SS133T-77 1 EA
....5 D802 HVD1SS133MT DIODE 1SS133T-77 1 EA
....5 D803 HVD1SS133MT DIODE 1SS133T-77 1 EA
....5 D804 HVD1SS133MT DIODE 1SS133T-77 1 EA
....5 D901 HVD1N5819T DIODE , SCHOTTKY 1N5819 1 EA
....5 D902 HVD1SS133MT DIODE 1SS133T-77 1 EA
....5 D911 HVD1SS133MT DIODE 1SS133T-77 1 EA
....5 D912 HVD1SS133MT DIODE 1SS133T-77 1 EA
....5 D914 C3A206 WIRE , COPPER SN95/PB5 , 0.6 0,018 M
....5 D917 HVD1SS133MT DIODE 1SS133T-77 1 EA
....5 D953 HVD1SS133MT DIODE 1SS133T-77 1 EA
....5 D954 CVD1N4003SRT DIODE , RECT 1N4003 1 EA
....5 D955 CVD1N4003SRT DIODE , RECT 1N4003 1 EA
....5 D956 CVD1N4003SRT DIODE , RECT 1N4003 1 EA
....5 D957 CVD1N4003SRT DIODE , RECT 1N4003 1 EA
....5 D961 HVD1N5819T DIODE , SCHOTTKY 1N5819 1 EA
....5 D962 CVD1N4003SRT DIODE , RECT 1N4003 1 EA
....5 D963 CVD1N4003SRT DIODE , RECT 1N4003 1 EA
....5 D964 HVD1SS133MT DIODE 1SS133T-77 1 EA
....5 D967 HVD1SS133MT DIODE 1SS133T-77 1 EA
....5 D968 HVD1SS133MT DIODE 1SS133T-77 1 EA
....5 D969 HVD1SS133MT DIODE 1SS133T-77 1 EA
....5 D973 HVD1SS133MT DIODE 1SS133T-77 1 EA
....5 D974 HVD1SS133MT DIODE 1SS133T-77 1 EA
....5 D975 HVD1SS133MT DIODE 1SS133T-77 1 EA
....5 D976 HVD1SS133MT DIODE 1SS133T-77 1 EA
....5 D979 HVDMTZJ5.1BT DIODE , ZENER MTZJ5.1B 1/2W 1 EA
....5 ET90 HJT1A025 PALTE , EARTH MET37-0002 1 EA
....5 ET91 HJT1A025 PALTE , EARTH MET37-0002 1 EA
....5 F901 KJCFC5S HOLDER , FUSE 2EA
....5 F902 KBA2D2500TLET FUSE (2.5A) 1EA
....5 IC97 HVIRE5VT28CATZ I.C , RESET (RICOH) 1 EA
....5 Q501 HVTKTA1268GRT T.R KTA1268GR 1 EA
....5 Q502 HVTKTA1268GRT T.R KTA1268GR 1 EA
....5 Q503 HVTKTA1268GRT T.R KTA1268GR 1 EA
....5 Q504 HVTKTA1268GRT T.R KTA1268GR 1 EA
....5 Q505 HVTKTA1268GRT T.R KTA1268GR 1 EA
....5 Q511 HVTKTC3200GRT T.R KTC3200GR 1 EA
....5 Q512 HVTKTC3200GRT T.R KTC3200GR 1 EA
....5 Q513 HVTKTC3200GRT T.R KTC3200GR 1 EA
....5 Q514 HVTKTC3200GRT T.R KTC3200GR 1 EA
....5 Q515 HVTKTC3200GRT T.R KTC3200GR 1 EA
....5 Q516 HVTKTC3200GRT T.R KTC3200GR 1 EA
....5 Q517 HVTKTC3200GRT T.R KTC3200GR 1 EA
....5 Q518 HVTKTC3200GRT T.R KTC3200GR 1 EA
....5 Q519 HVTKTC3200GRT T.R KTC3200GR 1 EA
....5 Q520 HVTKTC3200GRT T.R KTC3200GR 1 EA
....5 Q541 HVTKTC3198YT T.R KTC3198Y 1 EA
....5 Q542 HVTKTC3198YT T.R KTC3198Y 1 EA
....5 Q543 HVTKTC3198YT T.R KTC3198Y 1 EA
MAIN PCB ASS
Y
harman/kardon
AVR 360/230 Service Manual
Page 18 of 138

Harman Kardon AVR 360 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.07 %
Power output per channel (1KHz@6 Ohm)	130 W
Power output per channel (20-20KHz@8 Ohm)	55 W
Headphone outputs	1
Headphone connectivity	-
HDMI in	4
Digital audio optical in	3
Product color	Black, Silver
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
Handheld remote control	No
Apple docking compatibility	Not supported
Connectivity technology	Wired
Supported radio bands	AM, FM
Preset stations quantity	30

Weight and Dimensions

Depth	382 mm
Width	440 mm
Height	165 mm
Weight	13400 g
