Harman Kardon AVR 360

Level Ref. # Part Numbe
r
Description
Drawin
g
No
(
Value
)
Qt
y
UM
....5 C913 CCUS1H103KC CAP , CHIP 0.01UF 50V K 1 EA
....5 C914 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 1 EA
....5 C915 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 1 EA
....5 C916 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 1 EA
....5 C917 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 1 EA
....5 C918 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 1 EA
....5 C919 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 1 EA
....5 C920 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 1 EA
....5 C921 CCSNA0J220B CAP , CHIP TANTAL
(
22uF/6.3V, Nin
g
Xia Xin
g
R
i
XRCA45 XXX M XXX AT 1 EA
....5 C922 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 1 EA
....5 C923 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 1 EA
....5 C924 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C925 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C926 CCUS1H103KC CAP , CHIP 0.01UF 50V K 1 EA
....5 C927 CCUS1H103KC CAP , CHIP 0.01UF 50V K 1 EA
....5 C928 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 1 EA
....5 C929 CCUS1H103KC CAP , CHIP 0.01UF 50V K 1 EA
....5 C930 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 1 EA
....5 C931 CCSNA0J220B CAP , CHIP TANTAL
(
22uF/6.3V, Nin
g
Xia Xin
g
R
i
XRCA45 XXX M XXX AT 1 EA
....5 C932 CCSNA0J220B CAP , CHIP TANTAL
(
22uF/6.3V, Nin
g
Xia Xin
g
R
i
XRCA45 XXX M XXX AT 1 EA
....5 C933 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 1 EA
....5 C934 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 1 EA
....5 C935 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 1 EA
....5 C936 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 1 EA
....5 C937 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 1 EA
....5 C938 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 1 EA
....5 C939 CCUS1H470JA CAP , CHIP 47PF 50V J 1 EA
....5 C940 CCUS1H470JA CAP , CHIP 47PF 50V J 1 EA
....5 C941 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 1 EA
....5 C942 CCUI1C104KC CAP , CHIP(1005, 16V/0.1UF) 1 EA
....5 C943 CCSNA0J220B CAP , CHIP TANTAL
(
22uF/6.3V, Nin
g
Xia Xin
g
R
i
XRCA45 XXX M XXX AT 1 EA
....5 C944 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C945 CCSNA0J220B CAP , CHIP TANTAL
(
22uF/6.3V, Nin
g
Xia Xin
g
R
i
XRCA45 XXX M XXX AT 1 EA
....5 C946 CCUS1H103KC CAP , CHIP 0.01UF 50V K 1 EA
....5 C947 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C948 CCUS1H221JA CAP , CHIP 220PF 50V J 1 EA
....5 C949 CCUS1H102KC CAP , CHIP 1000PF 50V K 1 EA
....5 C950 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C951 CCUS1H221JA CAP , CHIP 220PF 50V J 1 EA
....5 C954 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C956 CCUS1H102KC CAP , CHIP 1000PF 50V K 1 EA
....5 C957 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C958 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C959 CCEC1ERV221T CAP , SMD ELECT(MANLEX, RV, 25V/220, 8X10) 1 EA
....5 C960 CCUS1H103KC CAP , CHIP 0.01UF 50V K 1 EA
....5 C961 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C962 CCEC1CRV471T CAP , SMD ELECT(MANLEX RV, 16V/470, 10X10) 1 EA
....5 C963 CCUS1H221JA CAP , CHIP 220PF 50V J 1 EA
....5 C964 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C965 CCUS1H103KC CAP , CHIP 0.01UF 50V K 1 EA
....5 C966 CCUS1H104KC CAP , CHIP 0.1UF 50V K 1 EA
....5 C967 CCUS1H103KC CAP , CHIP 0.01UF 50V K 1 EA
....5 C970 CCUS1H101JA CAP , CHIP 100PF 50V J 1 EA
....5 D902 CVDSS34SR DIODE , SCHOTTKY (40V,3A, DO-214AC) DELTA 1 EA
....5 D903 CVDSS34SR DIODE , SCHOTTKY (40V,3A, DO-214AC) DELTA 1 EA
....5 D904 CVD1SS378 DIODE , SCHOTTKY BARRIER (TOSHIBA) 1 EA
....5 D905 CVDSS34SR DIODE , SCHOTTKY (40V,3A, DO-214AC) DELTA 1 EA
....5 IC101 CVISII9185ACTU I.C , HDMI RX SW
(
80PIN TQFP
)
SILICON IMA
G
SII9185ACTU 1 EA
....5 IC102 CVITC74VHC08FT I.C (TOSHIBA) TC74VHC08FT 1 EA
....5 IC103 CVISII9134CTU IC , HDMI TX(100PIN, TQFP) 100PIN, TQFP 1 EA
....5 IC104 HVITC74HC4094FN I.C (TOSHIBA) TC74HC4094AFN 1 EA
....5 IC105 CVISN74ALVCH16827DGG I.C , BUFFER/DRIVER (TI) SN74ALVCH16827DGGR , TI 1 EA
....5 IC106 CVISN74ALVCH16827DGG I.C , BUFFER/DRIVER (TI) SN74ALVCH16827DGGR , TI 1 EA
....5 IC107 CVISN74ALVCH16827DGG I.C , BUFFER/DRIVER (TI) SN74ALVCH16827DGGR , TI 1 EA
....5 IC108 CVITC74VCX541FT I,C , OCTAL BUS BUFFER (TOSHIBA) 1 EA
....5 IC109 CVISII9135ACTU I.C , HDMI RX(REVISION A,TQFP-144P) 144PIN, TQFP 1 EA
....5 IC109 CVISII9135CTU IC , HDMI RX(144PIN, TQFP) 144PIN, TQFP 1 EA
....5 IC110 CVISN74ALVCH16827DGG I.C , BUFFER/DRIVER (TI) SN74ALVCH16827DGGR , TI 1 EA
....5 IC111 CVINJM2566V I.C , NJM2566AV(TE1) JRC 1 EA
....5 IC112 CVIFLI30336AC I.C , VIDEO PROCESSOR (GENESIS) FLI30336 1 EA
....5 IC113 CVIA3S56D40ETPG5 I.C, 256MB DDR SDRAM 1 EA
....5 IC114 CVIF49L320UA70TG I.C , 32M FLASH(48PIN TSOPI) F49L320UA70TG 1 EA
....5 IC115 CVIADV7342BSTZ I.C , VIDEO ENCODER ADV7342BSTZ 1 EA
....5 IC116 CVIMK2302S01T I.C , BUFFER (IDT) MK23020S-01T(IDT) 1 EA
....5 IC117 CVIA3S56D40ETPG5 I.C, 256MB DDR SDRAM 1 EA
....5 IC118 HVIKIC7SZ08FU I.C ,INPUT AND GATE (USV PACKAGE) KIC7SZ08FU-RTK 1 EA
....5 IC120 HVINJM2391DL125 I.C , CHIP REGULATOR (+2.5V) JRC 1 EA
....5 IC121 CVISI8005QTL IC , DCDC Converter (3.5A, SOP8) SANKEN 1 EA
....5 IC122 CVISI8005QTL IC , DCDC Converter (3.5A, SOP8) SANKEN 1 EA
....5 IC123 CVIAT24C02NSU18 I.C , EEPROM (2K) 1EA
....5 IC124 CVITC7MZ4052FK I.C , 4CH MUX (TOSHIBA) 1 EA
....5 IC125 HVIKIC7SZ08FU I.C ,INPUT AND GATE (USV PACKAGE) KIC7SZ08FU-RTK 1 EA
....5 IC126 CVINJM2595MTE1 I.C , VIDEO S/W (JRC) 1 EA
....5 IC127 CVIKIA1117S50 I.C , REGULATOR(SOT-223) KIA1117S50-RTK/P 1 EA
....5 IC128 CVINJM2845DL133 I.C , REGULATOR(3.3V, TO-252-3) JRC 1 EA
HDMI PCB ASS
Y
harman/kardon
AVR 360/230 Service Manual
Page 38 of 138
