Harman Kardon AVR 360

Level Ref. # Part Numbe
r
Description
Drawin
g
No
(
Value
)
Qt
y
UM
....5 IC129 CVINJM2845DL118 IC, NJM2845DL1-18(TE1) JRC 1 EA
....5 IC130 CVISI8005QTL IC , DCDC Converter (3.5A, SOP8) SANKEN 1 EA
....5 IC131 CVI74FCT38072DCGI I.C , CLOCK DRIVER (IDT) IDT74FCT38072DCGI , IDT 1 EA
....5 JK901 CJJ9H008Z JACK , HDMI (TYPE-A,SMT-19P) H050FS019G600BY 1 EA
....5 JK902 CJJ9H008Z JACK , HDMI (TYPE-A,SMT-19P) H050FS019G600BY 1 EA
....5 JK903 CJJ9H008Z JACK , HDMI (TYPE-A,SMT-19P) H050FS019G600BY 1 EA
....5 JK904 CJJ9H008Z JACK , HDMI (TYPE-A,SMT-19P) H050FS019G600BY 1 EA
....5 JK905 CJJ9H008Z JACK , HDMI (TYPE-A,SMT-19P) H050FS019G600BY 1 EA
....5 L801 CLZ9R009Z CHOKE COIL, CHIP ( FOR HDMI ) 1 EA
....5 L802 CLZ9R009Z CHOKE COIL, CHIP ( FOR HDMI ) 1 EA
....5 L803 CLZ9R009Z CHOKE COIL, CHIP ( FOR HDMI ) 1 EA
....5 L804 CLZ9R009Z CHOKE COIL, CHIP ( FOR HDMI ) 1 EA
....5 L805 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
....5 L806 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
....5 L807 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
....5 L808 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
....5 L809 CLZ9R005Z FERRITE , CHIP BEAD(60ohm, 1608) HCB1608KF-600T30 1 EA
....5 L810 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
....5 L811 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
....5 L812 CLZ9R005Z FERRITE , CHIP BEAD(60ohm, 1608) HCB1608KF-600T30 1 EA
....5 L813 CLZ9R005Z FERRITE , CHIP BEAD(60ohm, 1608) HCB1608KF-600T30 1 EA
....5 L814 CLZ9R005Z FERRITE , CHIP BEAD(60ohm, 1608) HCB1608KF-600T30 1 EA
....5 L815 CLZ9R005Z FERRITE , CHIP BEAD(60ohm, 1608) HCB1608KF-600T30 1 EA
....5 L816 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
....5 L817 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
....5 L818 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
....5 L819 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
....5 L820 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
....5 L821 CLZ9R005Z FERRITE , CHIP BEAD(60ohm, 1608) HCB1608KF-600T30 1 EA
....5 L822 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
....5 L823 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
....5 L824 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
....5 L825 CLZ9R005Z FERRITE , CHIP BEAD(60ohm, 1608) HCB1608KF-600T30 1 EA
....5 L826 CLQ13E220MRZ COIL , SMD POWER (22UH/3A) CMI-SSP12L80F-SERIES 1 EA
....5 L827 CLQ13E220MRZ COIL , SMD POWER (22UH/3A) CMI-SSP12L80F-SERIES 1 EA
....5 L828 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
....5 L829 CLZ9R005Z FERRITE , CHIP BEAD(60ohm, 1608) HCB1608KF-600T30 1 EA
....5 L830 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
....5 L831 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
....5 L832 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
....5 L833 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
....5 L834 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
....5 L835 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
....5 L836 CLZ9R005Z FERRITE , CHIP BEAD(60ohm, 1608) HCB1608KF-600T30 1 EA
....5 L837 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
....5 L838 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
....5 L839 CLZ9R005Z FERRITE , CHIP BEAD(60ohm, 1608) HCB1608KF-600T30 1 EA
....5 L840 CLZ9R005Z FERRITE , CHIP BEAD(60ohm, 1608) HCB1608KF-600T30 1 EA
....5 L841 CLZ9R005Z FERRITE , CHIP BEAD(60ohm, 1608) HCB1608KF-600T30 1 EA
....5 L842 CLZ9R005Z FERRITE , CHIP BEAD(60ohm, 1608) HCB1608KF-600T30 1 EA
....5 L843 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
....5 L844 CLZ9R005Z FERRITE , CHIP BEAD(60ohm, 1608) HCB1608KF-600T30 1 EA
....5 L845 CLZ9R005Z FERRITE , CHIP BEAD(60ohm, 1608) HCB1608KF-600T30 1 EA
....5 L846 CLZ9R005Z FERRITE , CHIP BEAD(60ohm, 1608) HCB1608KF-600T30 1 EA
....5 L847 CLZ9R005Z FERRITE , CHIP BEAD(60ohm, 1608) HCB1608KF-600T30 1 EA
....5 L848 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
....5 L849 CLZ9R005Z FERRITE , CHIP BEAD(60ohm, 1608) HCB1608KF-600T30 1 EA
....5 L850 CLZ9R005Z FERRITE , CHIP BEAD(60ohm, 1608) HCB1608KF-600T30 1 EA
....5 L851 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
....5 L852 CLZ9R005Z FERRITE , CHIP BEAD(60ohm, 1608) HCB1608KF-600T30 1 EA
....5 L853 CLZ9R005Z FERRITE , CHIP BEAD(60ohm, 1608) HCB1608KF-600T30 1 EA
....5 L854 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
....5 L855 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
....5 L867 CLZ9Z014Z FERRITE , CHIP BEAD(60ohm, 4516) HCB4516KF-600T60 1 EA
....5 L868 CLQ13E220MRZ COIL , SMD POWER (22UH/3A) CMI-SSP12L80F-SERIES 1 EA
....5 Q901 CVTKRC103S T.R , CHIP 1EA
....5 Q902 CVTKRC103S T.R , CHIP 1EA
....5 Q903 CVTKRC103S T.R , CHIP 1EA
....5 Q904 CVTKRC103S T.R , CHIP 1EA
....5 Q905 HVTKRA102S T.R , CHIP KRA102S 1 EA
....5 Q906 HVTKRA102S T.R , CHIP KRA102S 1 EA
....5 Q907 HVTKRA102S T.R , CHIP KRA102S 1 EA
....5 Q908 CVTUPA672T F.E.T (NEC) 1EA
....5 Q909 HVTKRA102S T.R , CHIP KRA102S 1 EA
....5 Q910 CVTUPA672T F.E.T (NEC) 1EA
....5 Q911 CVTUPA672T F.E.T (NEC) 1EA
....5 Q912 CVTUPA672T F.E.T (NEC) 1EA
....5 Q913 CVTUPA672T F.E.T (NEC) 1EA
....5 Q914 CVTKRC103S T.R , CHIP 1EA
....5 Q915 HVTKRC111S T.R , CHIP 1EA
....5 Q916 CVTKRC103S T.R , CHIP 1EA
....5 Q917 HVTKRC114S T.R , CHIP KRC114S 1 EA
....5 Q918 HVTKRC114S T.R , CHIP KRC114S 1 EA
....5 RN01 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN02 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
HDMI PCB ASS
Y
harman/kardon
AVR 360/230 Service Manual
Page 39 of 138
