Harman Kardon AVR 360

Level Ref. # Part Numbe
r
Description
Drawin
g
No
(
Value
)
Qt
y
UM
....5 RN03 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN04 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN05 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN06 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN07 CRJ104DJ220T RES,4ARRAY (22 OHM) 22X4/2012 1 EA
....5 RN08 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN09 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN10 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN11 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN12 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN13 CRJ104DJ220T RES,4ARRAY (22 OHM) 22X4/2012 1 EA
....5 RN14 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN15 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN16 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN17 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN18 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN19 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN20 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN21 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN22 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN23 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN24 CRJ104DJ220T RES,4ARRAY (22 OHM) 22X4/2012 1 EA
....5 RN25 CRJ104DJ220T RES,4ARRAY (22 OHM) 22X4/2012 1 EA
....5 RN26 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN27 CRJ062IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X2 MNR02M0APJ330 1 EA
....5 RN28 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN29 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN30 CRJ062IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X2 MNR02M0APJ330 1 EA
....5 RN31 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN32 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN33 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN34 CRJ104DJ100T RES, ARRAY, 10R (1608) 10R(1608) 1 EA
....5 RN35 CRJ104DJ100T RES, ARRAY, 10R (1608) 10R(1608) 1 EA
....5 RN36 CRJ062IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X2 MNR02M0APJ330 1 EA
....5 RN37 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN38 CRJ104DJ100T RES, ARRAY, 10R (1608) 10R(1608) 1 EA
....5 RN39 CRJ104DJ100T RES, ARRAY, 10R (1608) 10R(1608) 1 EA
....5 RN40 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN41 CRJ104DJ100T RES, ARRAY, 10R (1608) 10R(1608) 1 EA
....5 RN42 CRJ062IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X2 MNR02M0APJ330 1 EA
....5 RN43 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN44 CRJ104DJ100T RES, ARRAY, 10R (1608) 10R(1608) 1 EA
....5 RN45 CRJ104DJ100T RES, ARRAY, 10R (1608) 10R(1608) 1 EA
....5 RN46 CRJ104DJ103T RES, ARRAY, 10K (1608) 10K(1608) 1 EA
....5 RN47 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN48 CRJ104DJ103T RES, ARRAY, 10K (1608) 10K(1608) 1 EA
....5 RN49 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN50 CRJ104DJ103T RES, ARRAY, 10K (1608) 10K(1608) 1 EA
....5 RN51 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN52 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 RN53 CRJ062IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X2 MNR02M0APJ330 1 EA
....5 RN54 CRJ064IJ330T RES , CHIP NETWORK
(
1/16W, 33ohm, 1005X4 MNR04M0APJ330 1 EA
....5 R601 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
....5 R602 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
....5 R603 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
....5 R604 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
....5 R605 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
....5 R606 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
....5 R607 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
....5 R608 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
....5 R609 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
....5 R610 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
....5 R611 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
....5 R612 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
....5 R613 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
....5 R614 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
....5 R615 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
....5 R616 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
....5 R617 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
....5 R618 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
....5 R619 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
....5 R620 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
....5 R622 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
....5 R623 CRJ10DJ0R0T RES , CHIP (O OHM) 1608 SIZE 1 EA
....5 R624 CRJ10DJ472T RES , CHIP (4.7K OHM) 1608 SIZE 1 EA
....5 R625 CRJ10DJ0R0T RES , CHIP (O OHM) 1608 SIZE 1 EA
....5 R626 CRJ10DJ0R0T RES , CHIP (O OHM) 1608 SIZE 1 EA
....5 R627 CRJ10DJ220T RES , CHIP (22 OHM) 1608 SIZE 1 EA
....5 R628 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
....5 R629 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
....5 R631 CRJ10DJ0R0T RES , CHIP (O OHM) 1608 SIZE 1 EA
....5 R632 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
....5 R633 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
....5 R634 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
....5 R635 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
HDMI PCB ASS
Y
harman/kardon
AVR 360/230 Service Manual
Page 40 of 138
