Harman Kardon AVR 360

Level Ref. # Part Numbe
r
Description
Drawin
g
No
(
Value
)
Qt
y
UM
....5 R724 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
....5 R725 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
....5 R726 CRJ10DJ182T RES , CHIP (1.8K OHM) 1 EA
....5 R728 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
....5 R729 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
....5 R730 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
....5 R731 CRJ10DF8200T RES , CHIP 1% 820 OHM 1 EA
....5 R732 CRJ10DF1002T RES , CHIP 1% 10K /1/10W/F 1 EA
....5 R733 CRJ10DJ102T RES , CHIP (1K OHM) 1608 SIZE 1 EA
....5 R734 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
....5 R735 CRJ10DJ750T RES , CHIP (75 OHM) 1608 SIZE 1 EA
....5 R736 CRJ10DJ750T RES , CHIP (75 OHM) 1608 SIZE 1 EA
....5 R740 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
....5 R741 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
....5 R743 CRJ10DJ102T RES , CHIP (1K OHM) 1608 SIZE 1 EA
....5 R744 CRJ10DJ102T RES , CHIP (1K OHM) 1608 SIZE 1 EA
....5 R745 CRJ10DJ102T RES , CHIP (1K OHM) 1608 SIZE 1 EA
....5 R746 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
....5 R747 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
....5 R748 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
....5 R749 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
....5 R751 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
....5 R752 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
....5 R753 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
....5 R754 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
....5 R755 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
....5 R756 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
....5 R757 CRJ10DJ0R0T RES , CHIP (O OHM) 1608 SIZE 1 EA
....5 R758 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
....5 R759 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
....5 R760 CRJ10DJ0R0T RES , CHIP (O OHM) 1608 SIZE 1 EA
....5 R761 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
....5 R762 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
....5 R764 CRJ10DJ472T RES , CHIP (4.7K OHM) 1608 SIZE 1 EA
....5 R765 CRJ10DJ102T RES , CHIP (1K OHM) 1608 SIZE 1 EA
....5 R766 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
....5 R767 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
....5 R768 CRJ10DJ330T RES , CHIP (33 OHM) 1608 SIZE 1 EA
....5 R770 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
....5 R771 CRJ10DJ473T RES , CHIP (47K OHM) 1608 SIZE 1 EA
....5 R772 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
....5 R776 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
....5 R777 CRJ10DF2800T RES , CHIP(1/10W, 280ohm, 1608, 1%) 1/10W, 280OHM, 1608, 1% 1 EA
....5 R778 CRJ10DF1002T RES , CHIP 1% 10K /1/10W/F 1 EA
....5 R779 CRJ10DJ301T RES , CHIP 1608 1 EA
....5 R780 CRJ10DJ301T RES , CHIP 1608 1 EA
....5 R781 CRJ10DF3901T RES, CHIP 3.9KOHM/1608/1% 1 EA
....5 R782 CRJ10DF2200T RES , CHIP 1% (220 OHM) 1608 SIZE 1 EA
....5 R783 CRJ10DF2800T RES , CHIP(1/10W, 280ohm, 1608, 1%) 1/10W, 280OHM, 1608, 1% 1 EA
....5 R784 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
....5 R785 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
....5 R786 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
....5 R787 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
....5 R788 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
....5 R789 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
....5 R791 CRJ10DJ472T RES , CHIP (4.7K OHM) 1608 SIZE 1 EA
....5 R792 CRJ10DJ330T RES , CHIP (33 OHM) 1608 SIZE 1 EA
....5 R794 CRJ10DJ472T RES , CHIP (4.7K OHM) 1608 SIZE 1 EA
....5 R795 CRJ10DJ472T RES , CHIP (4.7K OHM) 1608 SIZE 1 EA
....5 R796 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
....5 R800 CRJ10DJ623T RES , CHIP 1608 SIZE (62K OHM) 1 EA
....5 R801 CRJ10DJ623T RES , CHIP 1608 SIZE (62K OHM) 1 EA
....5 R802 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
....5 R803 CRJ10DJ101T RES , CHIP (100 OHM) 1608 SIZE 1 EA
....5 R804 CRJ10DJ623T RES , CHIP 1608 SIZE (62K OHM) 1 EA
....5 R805 CRJ10DJ103T RES , CHIP (10K OHM) 1608 SIZE 1 EA
....5 R806 CRJ10DJ563T RES , CHIP 56K 1 EA
....5 R807 CRJ10DJ203T RES , CHIP 1608 1 EA
....5 R808 CRJ10DJ512T RES , CHIP (5.1K OHM) 1608 SIZE 1 EA
....5 R809 CRJ10DJ820T RES , CHIP (82 OHM) 1608 SIZE 1 EA
....5 R810 CRJ10DJ683T RES , CHIP (68K OHM) 1608 SIZE 1 EA
....5 R811 CRJ10DJ683T RES , CHIP (68K OHM) 1608 SIZE 1 EA
....5 R812 CRJ10DJ683T RES , CHIP (68K OHM) 1608 SIZE 1 EA
....5 R813 CRJ10DJ223T RES , CHIP (22K OHM) 1608 SIZE 1 EA
....5 R814 CRJ10DJ223T RES , CHIP (22K OHM) 1608 SIZE 1 EA
....5 R815 CRJ10DJ223T RES , CHIP (22K OHM) 1608 SIZE 1 EA
....5 R818 CRJ10DJ750T RES , CHIP (75 OHM) 1608 SIZE 1 EA
....5 X901 HOX27000E180S CRYSTAL , CHIP(27MHZ,SMD) HC-49/US 1 EA
....5 X902 COX19660E330S X-TAL, CHIP, 19.6608 MHz ( 33P ) 1 EA
...4 CMY1A297 HEAT SINK 1EA
...4 CQB1D022 A-ROHS/LABEL,SERIAL 1 EA
...4 C8AGB288 BOND (MAX) 0,3 G
...4 BN82 CWB1D00705058 WIRE ASS'Y (LOCKING TYPE, 2.5MM, 7PIN, 50MM) 1 EA
...4 CN54 CJP05GB46ZY WAFER 1EA
...4 CN56 CJP16GB143ZB DIP , SOCKET (16PIN, 2.54mm, ANGLE) 1 EA
HDMI PCB ASS
Y
harman/kardon
AVR 360/230 Service Manual
Page 42 of 138
